1336-L4 42336-200-51

Genius Drive Encoder Interface Board

MANUFACTUREROriginal Manufacturer
MODEL1336-L4 42336-200-51
PART NUMBER1336-L4 42336-200-51
PRODUCT TYPEGenius Drive Encoder Interface Board
SYSTEM FAMILYIndustrial AC Drive System
ORDER SUPPORTModel Verification

INDUSTRIAL AUTOMATION SPARE PARTS PARTNER

20 Years of Experience in Industrial Automation Supply

AMIKON supplies industrial automation spare parts to maintenance, engineering and procurement teams worldwide. Our focus includes discontinued and hard-to-find DCS, PLC and TSI components, helping customers identify the correct model, source replacement parts and support urgent maintenance requirements.

Discontinued Parts SourcingModel Identification SupportGlobal Customer SupportIn-Stock Supply Support
  • Item NO.:

    1336-L4 42336-200-51
  • Product Origin:

    USA
  • Lead Time:

    IN STOCK
  • Brand/Manufature:

    PLC module
  • Product Origin:

    USA
  • Lead Time:

    Brand New And 100% Original
  • Condition:

    IN STOCK
  • Certificate:

    12 Months

PLC Module

1336-L4 42336-200-51

Price and Availability Inquiry

The 1336-L4 42336-200-51 is a Drive Encoder Interface Board for industrial automation applications. Confirm the complete model, electrical ratings, interfaces and installed configuration before ordering.

Sales SupportDirect specialist contact
QuotationCurrent commercial details
DeliveryDHL · FedEx · UPS
Fast quotation support Send the model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LL Lisa LinSales Specialist
WhatsApp +86 18965423501
Request a Quote on WhatsApp Send Email Inquiry
For faster service, please include the model 1336-L4 42336-200-51 and required quantity in your inquiry.

PLC MODULE 1336-L4 42336-200-51

Technical Specifications

Verified identification, electrical, compatibility, installation and ordering data for 1336-L4 42336-200-51.

01Product IdentityBoard identification
MODEL1336-L4
PART NUMBER42336-200-51
PRODUCT TYPEContact Closure Interface Board
INTERFACE ROLEDigital contact input interface
02Contact Input LogicElectrical input levels
LOGIC POLARITYLow = true
LOW-STATE VOLTAGE3.0 V DC maximum
HIGH-STATE VOLTAGE4.0–5.0 V DC
INPUT SINK CURRENTApproximately 10 mA
03Input Circuit DataContact and current requirements
RECOMMENDED DEVICEReed-type contact
INPUT TERMINALSTB3 terminals 19–36
ISOLATED SUPPLY5 V DC
ISOLATED GROUNDIGND
04Board & Ordering DataInterface configuration
INPUT RESISTANCE10.7 kΩ
SERIES RESISTANCE470 Ω
MOUNTINGMain control board connector
ORDER REFERENCE1336-L4 42336-200-51
