Category: Drives

Product Line: SMC-Flex

Part Number: 150-F25NBDD

Weight: 15.00 lbs (6.80 kg)

Port: DPI

Enclosure Rating: IP 54 Type 2

Current Rating: 25 Amps

Cooling Method: Air Cooling

Storage Temperature: -4 to 176 °F

Operating Temperature (with enclosure): 32 to 122 °F

Ambient Relative Humidity: 0 to 95% (non-condensing)

The 150-F25NBDD SMC-Flex controller comes with a variety of starting and stopping modes that are suitable for different applications and a variety of operating and control options. Note that the custom control options are mutually exclusive, the users must specify the option that they want when they order the 150-F25NBDD controller, and if they need a different control option in the future, they will have to replace the controller with an upgrade. The 150-F25NBDD controller can be customized with the pump control option that reduces power surges when this controller is controlling a centrifugal pump. Pump control smoothly accelerates and decelerates the motor of the centrifugal pump and the operators can program the starting and stopping times. Do not use the pump control option for emergency stopping. Other control options include smart motor braking and slow speed with braking.
