Description：

The 2094-AC09-M02-S is an Integrated Axis Module (IAM) from the product family. This module is an essential part of implementing motion control as it hosts the major field connections such as Contactor enable (CED) connector, DC bus/AC input power (IPD) connector, Control power (CPD) connector, Motor power (MP) connector, Motor/resistive brake (BC) connector, I/O (IOD) connector. Aside from the variety of connectors available to the module’s front panel, the 2094-AC09-M02-S SERCOS and DPI connectivity is mounted near the bottom of the module, covered by a removable access door. SERCOS connections available to this module are Sercos transmit (Tx) connector and Sercos receive (Rx) connector as well as a single DPI connector for connection of optional peripherals and modules. The 2094-AC09-M02-S operates when supplied with an input supply voltage range of 195-264 VAC, 3-phase with nominal voltage of 230 VAC along an input frequency range pf 47-63 Hz while the control voltage of this module is designed for an input voltage of 95-264 VAC, 1-Phase with nominal values of 110VAC / 240 VAC. This module delivers an output voltage to the bus of 325 VDC with overvoltage detection when bus voltage reaches 415 VDC and undervoltage detection when bus voltage drops to 138 VDC. Additionally, it has a continuous output current to bus of 10 A and peak output current to bus of 20 A while the continuous output power is 6 kW and the peak output power is 12 kW and efficiency of 95%. The 2094-AC09-M02-S comes with an integrated Safe-Torque Off (STO) functionality which is a ISO 13849-1 PLe/SIL3-certified safety feature.

Specification：

Frequently asked questions

What is this module’s input power?

This module has an input power of around 195 to 264 Volts AC.

What type of module is the 2094-AC09-M02-S?

The 2094-AC09-M02-S is a Integrated Axis Module.

Where can I send the 2094-AC09-M02-S to be repaired?

DO Supply, Inc. offers a variety of repair services for the 2094-AC09-M02-S.

What is the continuous output power and peak output power of this module?

The 2094-AC09-M02-S has a continuous output power to bus of 6 kW and peak output power of 12 kW.

Does the 2094-AC09-M02-S come with an integrated Safe-Torque Off (STO) functionality?

Yes. This IAM module is capable of STO feature.

What is the supply voltage range required to operate this module?

Appropriate supply voltage is 195-264 VAC.

Product Applications

Packaging and Material Handling Factory: Used for chain-driven transfer tables, cranes, sorting machines and other equipment that require precise speed and position control.

Automobile Factory: Integrated into the production lines for vehicle assembly and general mechanical processing, cooperating with PLC for motion trajectory control.

Food and Pharmaceutical Factory: Supports bag-making machines, bottling lines, labeling machines and palletizing systems, meeting the requirements of high efficiency and flexible production switching.

Printing and Paper Industry: Applied to the linked production lines that require multi-axis synchronization to maintain the balance of paper/film tension.

Metal Processing and Forming: Such as intelligent flat steel tempering furnaces systems and various precision CNC processing equipment
