Input Voltage：

12Vdc, 24Vdc or 48Vdc

500VDC input to chassis,

500VDC input to output,

500VDC output to chassis

EN55032 Class A with margins

Switching Frequency

120kHz ± 5kHz

Output Voltage/Current

5Vdc/10A, 12Vdc/4A, 24Vdc/2A,36Vdc/1.5A, 48Vdc/1A or 72Vdc/0.5A are standard

Line/Load Regulation

± 1% combined from no load to full load

Dynamic Response

Max 5% voltage deviation for 10% to 50% load step, with better than 1msec recovery time

Output Ripple / Noise

Better than 1% of output voltage peak to peak or 0.2% RMS of the output voltage (20MHz BW)

Output Overload Protection

Current limiting with short circuit protection (hiccup mode)

Output Overvoltage Protection

Double regulator loop and transzorb clamp

Efficiency

Output voltage dependent.Typically 85% at full load

Operating Temperature Range

0ºC to 50ºC cold plate temperature

for full specification without derating

Extended temperature ranges available

Temperature Drift

0.03% per ºC over operating temperature range

Cooling

Conduction to customer heatsink or chassis and natural convection

Environmental Protection

Basic ruggedizing

Conformal coating

Humidity：5 – 95% non-condensing

Dimensions

FM: 66 x 38 x 163 mm
