The Advantech PCA-6108E is a Backplane Circuit Board designed for use in industrial embedded systems. Backplanes like the PCA-6108E are essential components in modular system designs as they provide the infrastructure for connecting multiple carrier cards or daughter boards in a system, enabling communication, power distribution, and signal routing between the various modules.

The PCA-6108E is part of Advantech’s line of modular backplanes designed for CompactPCI (cPCI) systems. The CompactPCI standard is commonly used for rugged, high-performance embedded computing in industrial, telecommunications, and transportation applications.

The PCA-6108E is designed in the CompactPCI form factor, which is a modular, high-performance standard based on PCI (Peripheral Component Interconnect).

The PCA-6108E typically provides 8 slots for CompactPCI cards (standard size: 3U). These slots support a variety of I/O modules, processor boards, communication cards, and other peripheral devices.

The PCA-6108E backplane has a 3U size with 8 slots for CompactPCI boards, ensuring efficient signal routing, power distribution, and mechanical support for the modules.

Typically supports J1 and J2 connectors for system interconnects, with J3/J4 connectors used for power distribution and additional signaling.

The PCA-6108E provides power to all connected modules, typically with +5V, +12V, and -12V rails for different system components.

The PCA-6108E backplane design optimizes signal integrity, minimizing crosstalk and interference between the modules.

PCA-6108E CompactPCI (cPCI) 3U backplane.

PCA-6108E Supports 8 slots for 3U-sized CompactPCI cards.

PCI Bus architecture (32-bit, 33 MHz).

PCA-6108E provides +5V, +12V, and -12V.

PCA-6108E Operating Temperature: 0°C to 60°C .

Storage Temperature: Typically -40°C to +85°C.

Relative Humidity: Typically 5% to 95%, non-condensing.
