B&R 8MS Synchronous Motors

8MSA4S.R0-31

Price and Availability Inquiry

The 8MSA4S.R0-31 is a self-cooled three-phase synchronous servo motor in size 4 short construction with resolver feedback and a 19 mm shaft.

Sales SupportDirect specialist contact

QuotationCurrent commercial details

DeliveryDHL · FedEx · UPS

Fast quotation support Send the model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LL Lisa LinSales Specialist

WhatsApp +86 18965423501

Email sales7@amikon.cn

Request a Quote on WhatsApp Send Email Inquiry

For faster service, please include the model 8MSA4S.R0-31 and required quantity in your inquiry.

8MSA4S.R0-31

Technical Specifications

Official identification, electrical, interface, installation and ordering data for the 8MSA4S.R0-31 resolver-feedback three-phase synchronous motor.

01Product IdentityOfficial model identification

ManufacturerB&R

Article Number8MSA4S.R0-31

Product DesignationResolver-Feedback Three-Phase Synchronous Motor

Product Family8MS Synchronous Motors

02Motor ConstructionPublished mechanical configuration

MOTOR PRINCIPLEThree-phase synchronous

COOLINGSelf-cooled

FRAMESize 4, short length

CONSTRUCTIONType A

03Feedback & ShaftResolver and output geometry

FEEDBACK OPTIONResolver R0

SHAFT DIAMETER19 mm k6

SHAFT LENGTH40 mm

CENTERING DIAMETER95 mm j6

04Mounting DimensionsOfficial outline data

OVERALL LENGTH K0155 mm

FLANGE FACE97 × 97 mm

MOUNTING HOLES4 × 9 mm

OPTION CHECKVerify complete suffix -31

8MSA4S.R0-31 Product Support

Frequently Asked Questions

Product-specific compatibility, application, installation, commissioning and ordering guidance for 8MSA4S.R0-31.

Which feedback device is fitted to this motor?

The R0 option identifies resolver feedback; the drive must support the corresponding resolver interface and wiring.

Which shaft dimensions matter for coupling selection?

The standard shaft is 19 mm k6 in diameter and 40 mm long, so the coupling bore, keying and load limits must be checked.

How large is the mounting interface?

The published flange face is 97 × 97 mm with a 95 mm j6 centering diameter and four 9 mm mounting holes.

Can this motor replace another size 4 motor without checks?

Not automatically. Confirm length, shaft, flange, feedback, connector orientation, winding data and the full option suffix.

How should alignment be handled during installation?

Use the centering pilot, align the coupling precisely and avoid forcing the shaft or transmitting excessive radial and axial load.

Which drive parameters must be commissioned?

Enter the motor data and resolver configuration from the nameplate and approved motor file, then verify rotation and feedback polarity at low speed.

Which ordering evidence is required?

Send model 8MSA4S.R0-31, the complete motor nameplate, connector photographs and the installed drive and cable references.
