Input Impedance: 20 kohm balanced, 10 kohm unbalanced

Input Sensitivity: +4dBu / 1.25 V

Signal Processing: CORE processing, 96kHz / 40bit floating point SHARK DSP, 24 bit AD/DA converters

Direct access Controls: 4 Presets

Remote Controls: PRONET control software

Network protocol: CANBUS

Amplifier Type: Class D with SMPS, Variable Switching Frequency

Output Power: 1000W + 1000W

Mains Voltage Range (Vac): 230V ±15% - 115 ±15% 50/60Hz.  (internally selectable)

IN / OUT Connectors: Neutrik XLR-M / XLR-F

IN / OUT Network Connectors: ETHERCON®(NE8FAV)

Mains Connector: PowerCon® (NAC3MPA)

Mains Link Connector: PowerCon® (NAC3MPB)

Cooling: Variable speed DC fan

Width: 746 mm (29.37")

Height: 341 mm (13.42")

Depht: 530 mm (20.86")

The AX2010-S61000-520 is a new powered line array element that combines superior sound quality with easiness and flexibility in a simple system with a very convenient priceto-performance ratio.  The AX2010-S61000-520 has been designed both for rental live sound applications and for fixed installations and has been engineered for the simplest use possible but without sacrificing anything in sound quality and performance.

The AX2010-S61000-520 offers a simple but innovative design in line array elements.  The simple concept of the WTW symmetrical design is implemented in an effective way in order to minimize the effects of potential beaming phenomena around the crossover frequency.  In order to minimize these effects, many different details have been carefully engineered, the first of them being the choice of the HF driver units.  The special light-weight diaphragm used in these drivers features a very low mechanical resonance, thus allowing a relatively low crossover frequency point that is placed in the 900Hz range.  Moreover, the orientation of the two woofers allows to minimize the interference effect between them, while the use of a mechanical-acoustic polyurethane filter represents a further help in minimizing the midrange beaming.
