Brand:Ebmpapst

Product Type:Centrifugal Fan

Model Number:R3G500-RA25-01

Diameter: 500 mm.

Voltage: 400V AC.

Power: 2.65 kW.

Current: 4.0 A.

Speed: 1700 RPM.

Airflow: Approx. 6845 m³/h.

Ingress Protection: IP54, dust and water-resistant.

Bearing Type: Ball bearing.

Housing Material: Aluminum alloy.

Operating Temperature Range: -25°C to 60°C.

The Ebmpapst R3G500-RA25-01 centrifugal fan is engineered for high-efficiency ventilation in industrial and HVAC applications. With a 500 mm diameter, this fan is designed to handle large volumes of air, providing an impressive airflow of around 6845 m³/h. It operates at 400V AC with a power rating of 2.65 kW, drawing a current of 4.0 A, and runs at a speed of 1700 RPM, ensuring optimal air circulation for cooling and ventilation purposes.

The fan is equipped with advanced electronic commutation (EC) technology, which enhances its energy efficiency by adjusting power consumption based on the load, making it both environmentally friendly and cost-effective. The aluminum alloy housing ensures a robust and lightweight design, while the ball bearing system contributes to extended operational life and reduced maintenance needs.

The IP54 protection rating provides resistance against dust and water, allowing the fan to perform reliably in harsh environments. It is capable of operating within a temperature range of -25°C to 60°C, ensuring versatility in different climate conditions. Ideal for use in systems requiring consistent airflow and energy-efficient performance, the R3G500-RA25-01 is perfect for industrial facilities, data centers, and other environments where effective ventilation is crucial.
