Location for the DIN rail  Plate fixture with unit earthing  Lock for DIN rail mounting

Location for external dual connector  Location for the cabling connectors:

of 24 V d.c. output power for the inputs  (available only for the remote units with 120 / 230 V a.c. power)

of the inputs used for configuration of ICMK-CS31   Visualization set for the status of the 8 inputs / 6 outputs

Location of the connector for the connection of input/output extensions

Location of the cabling connectors:

for the power supply

Location of the addressing rotate selectors (see enlargement)

Unit status visualization area:

POWER: power on

RUN: Blinking indicates the valid message received

ERR: On indicates error(s) present and blinking indicates configuration action
