Description：
The HIMA Z7306F (also officially designated as Z 7306) is a high-precision, industrial-grade shunt adapter module engineered specifically for safety-instrumented systems (SIS). Serving as a critical peripheral component for HIMA’s renowned HIMatrix safety control platform (including the F35 controller and F3 AIO 8/4 01 remote I/O modules), this plug-in module is designed to convert 4–20 mA current loops from field devices into stable voltage signals readable by the controller.Featuring an integrated 250 Ω high-precision resistor and built-in HART filtration circuitry, the Z7306F allows digital HART communication signals to seamlessly overlay and transmit across standard analog lines without signal degradation. It is an essential component for achieving advanced asset management and functional safety in critical process industries.
Specification：
|
Part Number |
Z7306F |
|
Brand |
HIMA |
|
Nominal Resistance |
250 Ω |
|
Resistance Tolerance |
± 0.1% |
|
Temperature Coefficient |
25 ppm/°C |
|
Maximum Power Loss |
0.4 W |
|
Operating Temperature Range |
0 °C ~ +60 °C |
|
Storage Temperature Range |
-40 °C ~ +85 °C |
|
Ambient Humidity |
5% ~ 95% RH (non-condensing) |
Frequently asked questions
Q1: What is the HIMA Z7306F Module used for?
A: The HIMA Z7306F is an industrial module used in HIMA safety and control systems.
Q2: What is the resistance value of the Z7306F Module?
A: The Z7306F module features a 250 Ω resistance, making it suitable for applications requiring precise current-to-voltage signal conversion and measurement functions.
Q3: What is the resistance tolerance of the Z7306F?
A: The resistance tolerance is ±0.1%, ensuring high measurement accuracy and consistent electrical performance.
Q4: What is the temperature coefficient of the Z7306F module?
A: The Z7306F has a temperature coefficient of 25 ppm/°C, meaning resistance changes only minimally with temperature variations.
Product Applications
Oil and Gas: Emergency Shutdown (ESD) systems and Furnace and Gas (F&G) systems for offshore platforms and refineries.
Chemical Industry: Monitoring reactors and piping systems to prevent safety accidents caused by high temperatures and pressures.
Power Generation and Nuclear Energy: Steam Turbine Control (TSI) and boiler safety protection to ensure grid stability and personnel safety.
Metallurgy and Heavy Industry: Blast furnace control and interlocking protection for large-scale production lines.
