Category

Attribute

Details

Environmental

Ambient Temperature (Operation)

-15°C to 70°C

Temperature (Storage)

-25°C to 70°C

Humidity (Operation)

Max. 95% RH, non-condensing

Humidity (Storage)

Max. 95% RH, non-condensing

Dimensions (H x W x D)

355 mm x 158 mm x 87 mm

Weight

1.34 kg

Power

Input Supply Voltage

24 VDC (+30%, -25%)

Nominal Current Consumption

Max. 0.75 A

Start-up Current

Max. 2.8 A

Power Consumption

Max. 20 W

Power Connectors

Screw terminals (slotted)

Cable Cross Section

2.5 mm²

Processor & Memory

Processor Type

Power PC Host processor P2041

Clock Frequency

1.5 GHz

Memory (RAM)

2 GB

Memory (Flash)

256 MB for application use

Interfaces

Serial Channels

24 insulated serial lines

Serial Connector Type

6 shielded RJ45 modular jacks

Physical Layer

RS232, RS422, RS485, NMEA 0183 Multidrop

Serial Bit Rate

Max. 115 kb/s

Digital Outputs

4 x opto-isolated, Max. 30 mA

Digital Inputs

4 x opto-isolated inputs

I/O Connectors

Cage clamps

Cable Cross Section

0.75 mm² and 2.5 mm²

Bit Rate (General Purpose I/O)

Max. 1 b/s

PROFIBUS Interface

2 x opto-isolated 9-pin female D-Sub

Bit Rate (PROFIBUS)

Max. 12 b/s
