Description	24–110 VAC Output
UL/CSA	5 x 20 mm
A IEC	5 x 20 mm
No. of Outputs	32
Module Width	Single-wide

Terminal Block Pin-out: 32-Point Discrete AC Output Modules (PPX:505–4632)

User Connection User Connection

AR = Not Used AC = User-Power

A1 = Output 1 A5 = Output 5

A2 = Output 2 A6 = Output 6

A3 = Output 3 A7 = Output 7

A4 = Output 4 A8 = Output 8

BR = Not Used BC = User-Power

B1 = Output 9 B5 = Output 13

B2 = Output 10 B6 = Output 14

B3 = Output 11 B7 = Output 15

B4 = Output 12 B8 = Output 16

CR = Not Used CC = User-Power

C1 = Output 17 C5 = Output 21

C2 = Output 18 C6 = Output 22

C3 = Output 19 C7 = Output 23

C4 = Output 20 C8 = Output 24

DR = Not Used DC = User-Power

D1 = Output 25 D5 = Output 29

D2 = Output 26 D6 = Output 30

D3 = Output 27 D7 = Output 31

D4 = Output 28 D8 = Output 32
