Analog Signal for PPX:505–6108A

The PPX:505–6108A analog signal is translated into a 12-bit digital word. Since the controller requires a 16-bit word for inputs, the 12-bit value from the converter is placed into a 16-bit word for transmittal to the controller. As shown in Figure 1-2, of the four bits not used for the converter magnitude, one is used to show the sign of the value, one is used to note overrange values, and the remaining two are not used and are set to zero.

Calculating Digital Words for the PPX:505–6108A

The PPX:505–6108A module has a resolution of 8 counts out of 32000. That is, the smallest unit into which the module divides a unipolar input is 1 part out of 4000. For a voltage input of 0 to +5 V, this division corresponds to a step of 1.25 mV. For a current input of 0 to 20 mA, a step of 5 µA can be resolved.

Use the following equations to calculate the digital word which results from a particular voltage or current input.

If the module is set for ±10 V input range, each step of eight counts corresponds to an input voltage change of 2.5 mV, and the digital word is

defined as follows:
