Siemens SIMATIC ET 200SP Technology Modules

6ES7138-6BA00-0BA0

Price and Availability Inquiry

The Siemens 6ES7138-6BA00-0BA0 is a armored 3300 XL 8 mm proximity probe configured with 3/8-24 UNF-2A thread, 0.0 in unthreaded length, 7.0 in overall case length, 1.0 m (3.3 ft) total length and clickloc connector with protector.

Sales SupportDirect specialist contact

QuotationCurrent commercial details

DeliveryDHL · FedEx · UPS

Fast quotation supportSend the complete model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LLLisa LinSales Specialist

WhatsApp+86 18965423501

Emailsales7@amikon.cn

Send Email Inquiry

For faster service, please include the model 6ES7138-6BA00-0BA0 and required quantity in your inquiry.

Siemens 6ES7138-6BA00-0BA0

Technical Specifications

Official encoder-interface, counting, supply and installation data for the TM PosInput 1 technology module.

01Product IdentityCore product information

ManufacturerSiemens

Article number6ES7138-6BA00-0BA0

Product typeTM PosInput 1

System familySIMATIC ET 200SP

02Encoder InterfacePosition and counting inputs

Incremental encoderRS-422

Absolute encoderSSI

Digital inputs2 DI

Digital outputs2 DQ

03Measurement DataTechnology-function limits

Load supply24 V DC

Permissible supply19.2-28.8 V DC

Frequency measurementUp to 4 MHz

Motion Control useSupported with compatible configuration

04Installation DataBaseUnit and mechanical details

Required BaseUnitType A0

Module width15 mm

WeightApprox. 45 g

Engineering checkMatch firmware and TIA Portal project

Siemens 6ES7138-6BA00-0BA0 Product Support

Frequently Asked Questions

Product-specific configuration, application and ordering guidance for 6ES7138-6BA00-0BA0.

What does TM PosInput 1 do?

It counts pulses and detects position from RS-422 incremental encoders or SSI absolute encoders in an ET 200SP station.

Which encoder types are supported?

The module supports RS-422 incremental encoders and SSI absolute encoders; the project parameters must match the installed encoder.

How are the onboard digital channels used?

Two DI and two DQ support gate, reference, capture and comparison functions according to the configured operating mode.

Why must the BaseUnit type be checked?

The module is designed for a type A0 BaseUnit; mechanical coding, potential groups and terminal assignment must match.

Can it be used for S7-1500 Motion Control?

Yes in supported configurations, but firmware, controller version and engineering project compatibility must be verified.

What should be backed up before replacement?

Save the hardware configuration, technology parameters, encoder settings, comparison values and diagnostic records.

What information is needed for ordering?

Provide the full article number, firmware version, BaseUnit code, encoder type, TIA Portal version, quantity and delivery country.
