SIEMENS · SIMATIC DP / PROFINET

6ES7158-3AD01-0XA0

PN/PN Coupler

MANUFACTURERSiemens
MODEL6ES7158-3AD01-0XA0
PART NUMBER6ES7158-3AD01-0XA0
PRODUCT TYPEPN/PN Coupler
SYSTEM FAMILYSIMATIC DP / PROFINET
ORDER SUPPORTOfficial Product Data

INDUSTRIAL AUTOMATION SPARE PARTS PARTNER

20 Years of Experience in Industrial Automation Supply

AMIKON supplies industrial automation spare parts to maintenance, engineering and procurement teams worldwide. Our focus includes discontinued and hard-to-find DCS, PLC and TSI components, helping customers identify the correct model, source replacement parts and support urgent maintenance requirements.

Discontinued Parts SourcingModel Identification SupportGlobal Customer SupportIn-Stock Supply Support

  • Item NO.:

    6ES7158-3AD01-0XA0

  • Order(MOQ):

    1

  • Lead Time:

    IN STOCK

  • Brand/Manufature:

    Siemens

  • Product Origin:

    Germany

  • Lead Time:

    IN STOCK

  • Condition:

    Brand New And 100% Original

  • Certificate:

    Coo
Inquire Now

SIEMENS · SIMATIC DP / PROFINET

6ES7158-3AD01-0XA0

Price and Availability Inquiry

Coupling module for exchanging data between two PROFINET networks, including PROFIsafe data.

Sales SupportDirect specialist contact
QuotationCurrent commercial details
DeliveryDHL · FedEx · UPS
Fast quotation support Send the model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LL Lisa LinSales Specialist
WhatsApp +86 18965423501
Request a Quote on WhatsApp Send Email Inquiry
For faster service, please include the model 6ES7158-3AD01-0XA0 and required quantity in your inquiry.

SIEMENS 6ES7158-3AD01-0XA0

Technical Specifications

Model-specific identification and technical data.

01Product IdentityExact model identification
ManufacturerSiemens
Article Number6ES7158-3AD01-0XA0
DesignationPN/PN Coupler
System FamilySIMATIC DP / PROFINET
02PROFINET InterfacesTwo-network interface data
Network Sides2 PROFINET networks
Ethernet Ports4 × RJ45
Transmission100BASE-TX
PROFINET Rate100 Mbit/s full duplex
03Network FunctionsSafety and diagnostic functions
Cyclic I/O Exchange, Max.1024 bytes
Supply ArrangementRedundant 24 V DC input
IRT Send Cycle250 µs–4 ms
Data Record Length, Max.8192 bytes
04Electrical & MechanicalLater Siemens 2017 dimensional data
Rated Supply24 V DC (20.4–28.8 V)
Dimensions (W × H × D)120 × 119.5 × 75 mm
Module WeightApprox. 283 g
Ingress ProtectionIP20

SIEMENS 6ES7158-3AD01-0XA0 PRODUCT SUPPORT

Frequently Asked Questions

Practical configuration, installation, compatibility and ordering guidance for 6ES7158-3AD01-0XA0.

01

How are data exchanged between the two PROFINET systems?

Configure the coupler as a device on each independent PROFINET side and map matching input/output data areas. Each controller owns its side; the coupler transfers the configured data rather than merging the two networks into one subnet.

02

Which connectors belong to each network side?

The unit provides four RJ45 ports across its two PROFINET interfaces. Trace the X1 and X2 sides in the Siemens connection diagram so the cables and device names are assigned to the intended controllers.

03

Can this coupler carry safety-related data?

Siemens documents PROFIsafe data transfer for the supported configuration. Validate the complete safety application, F-parameters and controller projects; the coupler itself does not replace safety acceptance testing.

04

How should power redundancy be wired and checked?

Provide the specified 24 V DC supply arrangement and verify both supply feeds where redundancy is required. Check the unit and port LEDs after startup so a failed feed or link is discovered before application testing.

05

Are MRP or shared-device features available for a network design?

The Siemens manual describes media redundancy and shared-device operation for supported firmware/configurations. Confirm the selected topology and configuration limits on both PN sides before enabling those features.

06

Which diagnostics are useful when one controller sees no data?

Start with per-side/per-port LEDs and controller diagnostics, then verify device name, IP assignment and matching I/O lengths. The documented SNMP/MIB-2 information can assist a managed-network investigation.

07

Which details should accompany a PN/PN Coupler replacement?

Specify 6ES7158-3AD01-0XA0, hardware/firmware revision, both PROFINET projects, mapped I/O lengths, any PROFIsafe use and the redundant-supply arrangement. Recheck the configuration before exchanging the unit.
