Specifications

EMG IDC32-1.1 Control Board is an industrial electronic circuit board used as a core module in EMG strip centering and alignment systems, which are part of the larger EMG strip guiding solutions for metal, paper, and continuous material processing lines. Although specific detailed specifications are not published in EMG's general product brochures, the IDC32-1.1 is widely listed in parts inventories as an IDC32 series centering device board, indicating its role in processing strip position detection signals and interfacing with control amplifiers and actuators to support strip position control.

Frequently asked questions：

Q1: What is the IDC32-1.1?

A1: The IDC32-1.1 is a control board designed for industrial , providing processing, control, and analog output capabilities.

Q2: What is the IDC32-1.1 power input?

A2: It typically operates on 24 V DC.

Q3: What is the IDC32-1.1 power consumption?

A3: The board consumes 10–20 W during operation.

Q4: What type of processor does it use?

A4: It is based on 16-bit or 32-bit industrial-grade microcontrollers, enabling reliable and precise control.

Q5: What analog outputs are available?

A5: It provides 10 V analog output, suitable for driving connected devices or sensors.

Product Applications

Steel Metallurgy: Used on production lines such as cold rolling, hot rolling, and galvanizing to control the movement of steel strips.

Automobile Manufacturing: Used for aligning sheet materials on automotive stamping lines and unwinding lines.

Aluminum Processing and Non-ferrous Metals: Ensuring that aluminum plates and aluminum foils do not shift during winding and unwinding.

Other Industries: Also includes the paper industry, textile industry, and general mechanical equipment manufacturing industry.

Core function

Correction control: IDC32-1.1 is the control core of the EMG correction system, responsible for receiving signals from sensors and processing them, thereby controlling the actuators (such as hydraulic stations or servo motors) to ensure that the strips (such as steel plates, aluminum foil, paper, etc.) on the production line always remain in the center position.

Signal processing: In a complex factory environment, it can stably process high-frequency centering data to ensure high precision in production.
