Description：

The CA306 144-306-000-321 is a piezoelectric accelerometer designed for extreme environments, primarily used in high-temperature applications in aerospace and industrial gas turbines. The CA306 piezoelectric sensor has a sensitivity of 50 pC/g, a dynamic measurement range up to 100 g, and a response frequency of 5 to 3000 Hz. In practical use, it requires an IPC70X signal conditioner to convert the output charge signal into a standard current or voltage signal. The CA306 144-306-000-321 piezoelectric accelerometer can operate stably over an ultra-wide extreme temperature range of -55°C to +500°C. The sensor is explosion-proof certified and is also available with an integrated mineral-insulated (MI) cable, protected by a stainless steel braided flexible conduit, effectively enhancing durability and corrosion resistance.

Specification：

Frequently asked questions

Q1: What is the Vibro-meter CA306 144-306-000-321 Piezoelectric Accelerometer used for?

A1: The CA306 Piezoelectric Accelerometer is used to measure machine vibration and acceleration in condition monitoring and machinery protection systems, helping identify imbalance, misalignment, bearing defects, and other mechanical issues.

Q2: What is the sensitivity of the CA306 accelerometer?

A2: The CA306 sensor provides a sensitivity of 50 pC/g ±5% at 120 Hz, ensuring accurate and stable vibration measurements.

Q3: What is the transverse sensitivity of the CA306 accelerometer?

A3: The CA306 transverse sensitivity is less than 5%, minimizing the influence of vibrations from unwanted directions and improving measurement accuracy.

Q4: What is the resonant frequency of the CA306?

A4: The CA306 accelerometer has a resonant frequency greater than 15 kHz, allowing reliable operation across its specified frequency range.

Q5: What is the frequency response range of the CA306 sensor?

A5: The CA306 frequency response is 5 Hz to 3,000 Hz, making it suitable for a wide range of industrial vibration monitoring applications.

Product Applications

Aerospace and Gas Turbine Plants: Used to monitor the casing vibration of aircraft engines and industrial gas turbines to prevent catastrophic failures during high-temperature, high-speed operation.

Coal Power Plants and Nuclear Power Plants: Used to monitor abnormal vibrations in large steam turbines, generator bearings, and high-temperature, high-pressure pipelines.

Petrochemical and Refinery Plants: Used for 24/7 equipment health monitoring (PHM) of core rotating machinery such as large compressors and pump sets in harsh, high-temperature environments such as oil refining and natural gas transportation.

Heavy Metallurgy and Steel Plants: Applied to complex industrial environments involving high temperatures and strong vibrations, such as blast furnace peripheral equipment and large rolling mills.
