The system is based around a TQ401 non-contact sensor and an IQS450 signal conditioner. Together, these form a calibrated proximity measurement system in which each component is interchangeable. The system outputs a voltage or current proportional to the distance between the transducer tip and the target, such as a machine shaft.
The IQS450 signal conditioner contains a high-frequency modulator/demodulator that supplies a driving signal to the transducer. This generates the necessary electro-magnetic field used to measure the gap. The conditioner circuitry is made of high-quality components and is mounted in an aluminium extrusion.
Specification：
|
Part Number |
IQS450 S3960 204-450-000-002-A1-B23-H5-I0 |
|
Voltage at minimum gap |
−1.6 V |
|
Voltage at maximum gap |
−17.6 V |
|
Voltage dynamic range |
16 V |
|
Output impedance |
500 Ω |
|
Short-circuit current |
45 mA |
|
Supply voltage range |
−20 V to −32 V |
|
Bias current |
−13 mA ±1 mA (Max. −25 mA) |
|
Output current range |
−15.5 mA to −20.5 mA |
|
Supply input capacitance |
1 nF |
|
Supply input inductance |
100 µH |
Frequently asked questions
Q1: What is the Vibro-meter IQS450 S3960 204-450-000-002-A1-B23-H5-I0 Signal Conditioner used for?
A1: The IQS450 Signal Conditioner is used to process signals from proximity sensors and displacement transducers, providing accurate and stable outputs for machinery protection, condition monitoring, and industrial systems.
Q2: What is the voltage at the IQS450 minimum GAP position?
A2: The IQS450 voltage at the minimum GAP position is −1.6 V, providing a reference point for displacement and position measurements.
Q3: What is the output impedance of the IQS450 signal conditioner?
A3: The IQS450 has an output impedance of 500 Ω, ensuring compatibility with connected monitoring and control equipment.
Q4: What is the IQS450 short-circuit current rating of the unit?
A4: The IQS450 signal conditioner provides a short-circuit current of 45 mA, helping protect the output circuitry under fault conditions.
Q5: What is the IQS450 supply input inductance?
A5: The IQS450 supply input inductance is 100 µH, supporting stable electrical performance and signal conditioning.
Product Applications
Power plants and energy industry: Vibration and axial position monitoring of various rotating machinery, including large water turbines, steam turbines, and gas turbines.
Oil, gas, and petrochemical industry: Monitoring the safe operation of high-speed centrifugal compressors, turbine compressors, and high-power pump units.
Metallurgy and heavy industry: Condition monitoring of blast furnace blowers, large feedwater pumps, and generator sets.
Water conservancy and water treatment: Measurement of shaft displacement and runout of large submersible pumps and hydro-generator units.
