Voltage at min. / max. gap : −1.6 V / −17.6 V

Measurement range : 16 V (corresponding to 12 mm)

Current at min. / max. gap : −15.5 mA / −20.5 mA

Measurement range : 5 mA (corresponding to 2 or 4 mm)

Output sensitivity : See Operation on page 3 and IQS900 signal conditioner on

page 18

Nominal output signal

• Without diagnostics : −15.5 to −20.5 mA

• With diagnostics : −15.5 to −20.5 mA indicates normal operation.

Other current values (>−15.5 or <−20.5 mA) indicate a problem

with the measurement chain (sensor, cabling or signal conditioner).

Output impedance : >60 kΩ.

The IQS900 signal conditioner contains a high-frequency modulator/demodulator that supplies a driving signal to a TQ9xx sensor. This generates an electromagnetic field in the tip of the sensor, which generates eddy-currents in the metallic target. When the target moves, the eddy-currents change, which causes a change in the electrical characteristics of the TQ9xx that the signal conditioner converts into a signal that is proportional to the distance to the target.

The IQS900’s output is an analogue signal consisting of a dynamic component (AC) that corresponds to the measured vibration (displacement) and a quasi-static component (DC) that corresponds to the measured gap. The output can be configured as a current or a voltage signal, suitable for transmission to a monitoring system via current (2-wire) or voltage (3-wire) transmission cables, respectively.
