Vibro-meter TQ402 111-402-000-013 S3960 A1-B1-C042-D000-E010-F0-G000-H10 Non-contact proximity transducer
Brand/Manufature:
Vibro-meterProduct Origin:
SwitzerlandLead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
CooFor additional discounts, please contact our five-star sales manager Lisa Lin.
|
|
Description：
The TQ402/TQ412, EA402 and IQS900 form a proximity measurement system, from Meggitt’s vibro-meter® product line. This proximity measurement system allows contactless measurement of the relative displacement of moving machine elements.
The system is based around a TQ402 or TQ412 non-contact sensor and an IQS900 signal conditioner. Together, these form a calibrated proximity measurement system in which each component is interchangeable. The system outputs a voltage or a current proportional to the distance between the transducer tip and the target, such as a machine shaft.
The TQ402 and TQ412 transducers can be matched with a single EA402 extension cable to effectively lengthen the front-end. Optional housings, junction boxes and interconnection protectors are available for the mechanical and environmental protection of the connection between the integral and extension cables.
Specification：
|
Part Number |
TQ402 111-402-000-013 S3960 A1-B1-C042-D000-E010-F0-G000-H10 |
|
Current at min. / max. gap |
−15.5 mA / −20.5 mA |
|
Current measurement range |
5 mA |
|
Current output without diagnostics |
−15.5 to −20.5 mA |
|
Current output with diagnostics |
−15.5 to −20.5 mA = normal operation |
|
Voltage at min. / max. gap |
−1.6 V / −17.6 V |
|
Voltage measurement range |
16 V |
|
Small signal output impedance (D) |
<100 Ω |
|
Nominal output voltage range |
−0.8 to −8.8 V |
|
Output impedance (up to 20 kHz) |
<15 kΩ |
|
Operating & storage temperature |
−40 to 85°C (−40 to 185°F) |
|
Sensitivity |
8 mV/µm (200 mV/mil) |
Frequently asked questions
Q1: What is the Vibro-meter TQ402 111-402-000-013 Non-contact Proximity Transducer used for?
A1: The TQ402 Non-contact Proximity Transducer is used to measure shaft displacement, shaft position, vibration, eccentricity, and runout in rotating machinery monitoring and protection systems.
Q2: What is the measurement range of the TQ402 transducer?
A2: The TQ402 transducer provides a measurement range of 16 V, enabling accurate monitoring of shaft movement and displacement.
Q3: What is the output voltage range of the TQ402 transducer?
A3: The TQ402 nominal output voltage range is −0.8 V to −8.8 V, providing a stable signal for machinery monitoring equipment.
Q4: What is the output impedance of the TQ402?
A4: The TQ402output impedance is less than 15 kΩ up to 20 kHz, ensuring reliable signal transmission and compatibility with associated monitoring systems.
Q5: What is the TQ402 operating and storage temperature range?
A5: The TQ402 transducer is rated for both operation and storage from −40°C to +85°C (−40°F to +185°F).
Product Applications
Power plants (thermal/nuclear/hydropower): Vibration and axial movement monitoring of steam turbine, gas turbine, and generator set bearings.
Oil and gas, petrochemical plants: Large-scale hydrogenation compressors, natural gas transmission turbine compressors, and high-pressure pumps.
Heavy industry, metallurgy, and steel plants: Critical rotor condition monitoring of large blast furnace blowers and high-power exhaust systems.
