Brand/Manufature:
Vibro-meterProduct Origin:
SwitzerlandLead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
CooFor additional discounts, please contact our five-star sales manager Lisa Lin.
|
|
Description：
Vibro-Meter TQ403 111-403-000-012 is a non-contact proximity transducer designed for highly accurate shaft displacement, vibration, eccentricity, and position measurements in rotating machinery. As part of the TQ403 / EA403 / IQS450 Proximity Measurement System, it is widely used in steam turbines, gas turbines, compressors, pumps, generators, and other critical rotating equipment for machinery protection and condition monitoring applications.
The TQ403 utilizes eddy-current measurement technology and features an 18 mm sensing coil, a robust stainless-steel probe body, and a high-temperature Torlon sensing tip. It is designed to operate with an IQS450 signal conditioner and provides a measurement range of up to 12 mm, delivering stable and reliable performance even in harsh industrial environments.
Specification：
|
Model |
TQ403 |
|
Part Number |
111-403-000-012 |
|
Product Type |
Proximity Transducer |
|
Measurement Principle |
Eddy Current, Non-Contact |
|
Measurement Range |
12 mm |
|
Probe Coil Diameter |
Ø18 mm |
|
Thread Type |
M20 × 1.5 |
|
Body Length |
36 mm |
|
Unthreaded Length |
0 mm |
|
Integral Cable Length |
1 m ±10% |
|
Probe Operating Temperature |
-40°C to +180°C |
|
Short-Term Survival Temperature |
Up to +220°C |
|
Cable Operating Temperature |
-40°C to +200°C |
|
Vibration Resistance |
5 g peak, 10–500 Hz |
|
Shock Resistance |
15 g peak, 11 ms |
Frequently asked questions
Q1: What is the Vibro-meter TQ403 111-403-000-012 Industrial Proximity Sensor used for?
A1: The TQ403 Industrial Proximity Sensor is used for non-contact measurement of shaft displacement, shaft position, vibration, and runout in rotating machinery monitoring and protection systems.
Q2: What thread type does the TQ403 sensor use?
A2: The TQ403 sensor features an M20 × 1.5 thread, allowing secure installation in a wide range of industrial applications.
Q3: What is the body length of the TQ403 sensor?
A3: The TQ403 has a body length of 36 mm, making it suitable for installations where space is limited.
Q4: What is the TQ403 cable operating temperature range?
A4: The TQ403 sensor cable is rated for operation from -40°C to +200°C (-40°F to +392°F), enabling reliable performance in harsh environments.
Q5: What vibration resistance does the TQ403 provide?
A5: The TQ403 sensor is designed to withstand 5 g peak vibration within a frequency range of 10 to 500 Hz, ensuring stable operation in demanding machinery applications.
Product Applications
Thermal/hydropower plants: Used for monitoring the main shafts of large steam turbines, gas turbines, water turbines, and generators.
Petrochemical and natural gas plants: Used for dynamic monitoring of the shaft systems of large turbine compressors, high-power pumps, and fans.
Petrochemical and natural gas plants: Used for dynamic monitoring of the shaft systems of large turbine compressors, high-power pumps, and fans.
Heavy industry and manufacturing plants (such as steel mills and mining plants): Used for monitoring bearing vibration in large blast furnace blowers and large transmission machinery.
