The Yokogawa MRI114 is a Relay Output Board designed for use in Yokogawa’s CENTUM series of Distributed Control Systems (DCS), including CENTUM CS 3000 and CENTUM VP. This MRI114  module provides the necessary interface for controlling external devices using relay outputs, making it an essential component for in process control environments. The MRI114 board enables direct switching of external equipment, such as motors, alarms, and other electrical devices, in response to control system outputs.

The Yokogawa MRI114 Relay Output Board is part of the I/O modules for the CENTUM DCS platform. The board provides digital relay outputs, which are used to control external devices based on the signals from the DCS controller.

This MRI114  module is engineered to provide high operational flexibility, ease of installation, and reliable performance in demanding industrial environments.

Model: MRI114

Manufacturer: Yokogawa

Type: Relay Output Board

Output Type: Relay Contact Outputs

Relay Contact Rating:

AC Loads: Typically rated for 250V AC, up to 5A (resistive load).

DC Loads: Typically rated for 30V DC, up to 5A (resistive load).

Output Channels:

The MRI114 module typically provides 8 relay output channels.

The MRI114  relay outputs are typically galvanically isolated from the control system to prevent electrical interference and ensure safety.

Electrical Power Requirements

Power Supply: 24V DC

Power Consumption: 2 to 5 watts

Operating Temperature:0°C to 60°C (32°F to 140°F)

Storage Temperature: -20°C to 70°C (-4°F to 158°F).

Humidity: 5% to 95%.

Dimensions: 180 mm x 110 mm x 25 mm (Height x Width x Depth).

Weight: 0.2 to 0.5 kg
