The Yokogawa NFCP501-W05 S2 is a CPU Module designed for use in the CENTUM VP process system. This module plays a crucial role in processing control,managing data communication, and executing user-defined programs in industrial applications.

NFCP501-W05 S2 Ambient temperature：

Operation： 0° to 55°C

Transportation/storage -40° to 85°C

NFCP501-W05 S2 Ambient humidity:

Operation 5 to 95 %RH (no condensation)

Transportation/storage 5 to 95 %RH (no condensation)

NFCP501-W05 S2 Rate of change in temperature :

Operation Within ±10°C/h

Transportation/storage Within ±20°C/h

Dust :0.3 mg/m3 or less

Protection class:IP20

Resistance to corrosive gases:ANSI/ISA S71.04 Class G2 (Standard) (ANSI/ISA S71.04 Class G3, option)

Resistance to vibration :0.15 mm P-P (5 to 58 Hz), 1 G (58 to 150 Hz)

Resistance to shock :15 G, 11 ms (during power-off, for sine half-waves in XYZ-directions)

Altitude:2000 m or less

NFCP501-W05 S2 Noise:

Electric field: 3 V/m or less (26 MHz to 1 GHz)

Magnetic field:30 A/m (AC) or less, 400 A/m (DC) or less

Electrostatic discharge: 4 kV or less contact discharge, 8 kV or less aerial discharge

Grounding:Apply the grounding system which is defined by the rules and standards of the country or the region.

Cooling: Natural air cooling
