Description：

The graphic operator terminal with catalog number 2711-T10C8 is part of the 2711 PanelView Standard operator terminals. It is specifically part of the PanelView Plus 1000 operator terminals which comes with standard capabilities such as a 10.1-inch colored display screen with resolution of 640 x 480 pixels, touch input interface and integral 1008 Kbytes internal flash memory.

The 2711-T10C8 has specific feature provided by the built-in Data Highway Plus (DH+) communication port and RS232 Printer interface. The DH+ port is used for exchanging data with partner controllers such as PLC5, SLC500, and other PLC , even with 3rd party devices with support for DH+ protocol as well. DH+ uses a 3-wire cable, which may be implemented in long distances and support communication with one or more controllers. The secondary port which is the RS232 is used for communicating with alarm printers, enabling printing and documenting of alarms and events for historization and reports.

The 2711-T10C8 is a flush mounted to an enclosure and supports horizontal orientation only. It requires mounting clearance of 51 mm or 2 inches on all sides to ensure adequate air flow as well as working space for installation of additional components intended for the operator terminal.

Specification：

Frequently asked questions

Q1: What is the 2711-T10C8 Operator Terminal used for?

A1: The 2711-T10C8 is a PanelView operator terminal designed to provide a human-machine interface (HMI) for monitoring, controlling, and interacting with industrial systems.

Q2: What power source does the 2711-T10C8 require?

A2: The 2711-T10C8 terminal operates on a power source rating of 100 to 240 VAC.

Q3: How much memory is available in the 2711-T10C8 terminal?

A3: The 2711-T10C8 is equipped with 256 KB of memory for application storage and operation.

Q4: What is the operating temperature range of the 2711-T10C8 terminal?

A4: The 2711-T10C8 operating temperature range is 0°C to 55°C (32°F to 131°F).

Q5: What is the 2711-T10C8 heat dissipation rating of the unit?

A5: The 2711-T10C8 terminal has a heat dissipation rating of 39 W (132 BTU/hr).

Product Applications

Automotive manufacturing and parts production lines: Used in complex stamping, welding, and assembly lines to display fault codes, cycle times, and set parameter formulations.

Chemical and petrochemical industries: Used at the front end of reaction vessels and batching control systems (DCS/PLC) to monitor temperature and pressure transmitter data and valve on/off status in real time.

Water treatment and environmental engineering: Used in sewage treatment and waterworks pump station control to visually display water flow pipeline diagrams and pump unit operating status.

Paper, printing, and packaging industries: Used for tension adjustment and alarm information recording in multi-axis linkage equipment and winding/unwinding control.
