ABB 1SDA083360R1 Ekip UP Protect Digital Unit

1SDA083360R1
1SDA083360R1
1SDA083360R1

ABB 1SDA083360R1 Ekip UP Protect Digital Unit

✉  INQUIRE NOW

ABB · Ekip UP

1SDA083360R1

Ekip UP Protect Digital Unit

MANUFACTURERABB
MODEL1SDA083360R1
PART NUMBER1SDA083360R1
PRODUCT TYPEEkip UP Protect Digital Unit
SYSTEM FAMILYEkip UP
ORDER SUPPORTModel Verification

INDUSTRIAL AUTOMATION SPARE PARTS PARTNER

20 Years of Experience in Industrial Automation Supply

AMIKON supplies industrial automation spare parts to maintenance, engineering and procurement teams worldwide. Our focus includes discontinued and hard-to-find DCS, PLC and TSI components, helping customers identify the correct model, source replacement parts and support urgent maintenance requirements.

Discontinued Parts SourcingModel Identification SupportGlobal Customer SupportIn-Stock Supply Support
  • Item NO.:

    1SDA083360R1
  • Product Origin:

    Sweden
  • Lead Time:

    IN STOCK
  • Brand/Manufature:

    ABB
  • Product Origin:

    Sweden
  • Lead Time:

    Brand New And 100% Original
  • Condition:

    IN STOCK
  • Certificate:

    Coo

ABB Ekip UP

1SDA083360R1

Price and Availability Inquiry

The ABB 1SDA083360R1 is an Ekip UP Protect digital unit for monitoring and protection functions in compatible low-voltage distribution installations.

Sales SupportDirect specialist contact
QuotationCurrent commercial details
DeliveryDHL · FedEx · UPS
Fast quotation support Send the model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LL Lisa LinSales Specialist
WhatsApp +86 18965423501
Request a Quote on WhatsApp Send Email Inquiry
For faster service, please include the model 1SDA083360R1 and required quantity in your inquiry.

ABB 1SDA083360R1

Technical Specifications

Verified identification, configuration, interface and application data for 1SDA083360R1.

01Product IdentitySource-verified technical data
ManufacturerABB
Order Code1SDA083360R1
Product DesignationEkip UP Protect
Product FamilyEkip UP
02Electrical RatingsSource-verified technical data
Operating VoltageUp to 1000 V
Operating Current100–6300 A
Operating Frequency50–60 Hz
Protection DegreeIP40
03Supply Module DataABB Ekip UP series data
Supply Voltage21.5–53 V DC
Power Without Accessories4 W maximum
Power With Accessories10 W maximum
Inrush Current2 A for 20 ms
04Connection DataABB Ekip UP series data
External Cable SizeAWG 22–16
Maximum Cable Diameter1.4 mm
Auxiliary Supply ModuleEkip Supply 24–48 V DC
Local CommunicationLocal Bus through Ekip Supply

ABB 1SDA083360R1 Product Support

Frequently Asked Questions

Practical compatibility, application, installation, commissioning and ordering guidance for 1SDA083360R1.

01

What is the function of Ekip UP Protect?

Ekip UP Protect is an ABB low-voltage digital unit for monitoring electrical quantities and providing protection functions in an installed distribution system.

02

How is it different from Ekip UP Monitor?

The Protect version adds protection capability to monitoring. Use the complete order code 1SDA083360R1 to avoid confusing it with Monitor, Protect+, Control or Control+ variants.

03

Which external components are required?

The application requires compatible current sensors and a rating plug. The exact sensor range, wiring and accessory set must match the installation design.

04

What auxiliary supply is used?

The documented accessory is Ekip Supply 24–48 V DC. Confirm the installed supply module and wiring before energizing the unit.

05

Can settings from another installation be copied directly?

No. Protection thresholds, timing, sensor ratios, network settings and trip logic must be engineered and verified for the specific switchboard and protection study.

06

What commissioning tests are necessary?

Verify sensor polarity and scaling, auxiliary supply, measurements, alarms, communication and the complete protection/trip chain using the approved commissioning procedure.

07

What information should be included in an order?

Provide 1SDA083360R1, system single-line data, current sensor type, rating plug, supply voltage, communication accessories and required quantity.
