ABB 3BHE024747R0101 PCB BOARD Supplier,ABB 3BHE024747R0101 PCB BOARD Manufacturer,ABB 3BHE024747R0101 PCB BOARD Factory

Product Categories

New Products

ABB ACS2000 Drive

3BHE024747R0101 GDC801A101

Price and Availability Inquiry

ABB lists 3BHE024747R0101 as a Crowbar Board / Driver Board in its ACS2000 spare-parts manual. Confirm the GDC801A101 marking and installed equipment records before ordering.

Sales SupportDirect specialist contact

QuotationCurrent commercial details

DeliveryDHL · FedEx · UPS

Fast quotation support Send the model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LL Lisa LinSales Specialist

WhatsApp +86 18965423501

Email sales7@amikon.cn

Request a Quote on WhatsApp Send Email Inquiry

For faster service, please include the model 3BHE024747R0101 GDC801A101 and required quantity in your inquiry.

ABB 3BHE024747R0101 GDC801A101

Technical Specifications

ABB spare-parts catalog identity and frame-specific locations for this Crowbar Board.

01Product IdentityABB board and order reference

ManufacturerABB

Part number3BHE024747R0101

Board designationGD C801 A101

Catalog descriptionCrowbar Board

02Catalog ClassificationACS2000 spare-parts manual

Drive familyACS2000

Manual scope4 kV Frames 1, 2 and 3

Catalog categoryControl electronics

SubcategoryPrinted circuit boards

03Frame 1 LocationABB Figure 7A spare-parts list

Cabinet areaPhase Module Section

SubassemblyNP Frame

Catalog item3.12

Cabinet quantity1

04Frame 2 LocationABB Figure 9B spare-parts list

Cabinet areaIFU Section

LocationRight Cabinet, Right Side

Catalog item2.6

Cabinet quantity1

ABB 3BHE024747R0101 GDC801A101 Product Support

Frequently Asked Questions

ACS2000 crowbar-board fitment, service handling and ordering checks.

Which ACS2000 frame layouts list part 3BHE024747R0101?

ABB’s ACS2000 4 kV spare-parts manual lists this crowbar board for Frames 1 and 2. Check the drive-specific parts list before ordering for another frame.

Where is the crowbar board shown in those layouts?

Frame 1 shows it as item 3.12 in the phase-module NP frame; Frame 2 shows it as item 2.6 in the right IFU cabinet.

Does the board order include the crowbar stack?

No. ABB lists the crowbar board and crowbar stack separately. Match the required assembly to the installed drive’s bill of materials.

How should a replacement board be matched to the drive?

Compare the full 3BHE024747R0101 number, drive frame and unit-specific spare-parts list with the installed hardware.

Which handling steps protect the PCB before fitting?

Inspect it on receipt, keep it in antistatic packaging and use grounded ESD precautions when handling the board.

Who should replace this board inside an ACS2000?

Qualified personnel should isolate, lock out, discharge and ground the main and auxiliary supplies under ABB’s drive procedure before service.

How is the drive checked after a crowbar-board change?

Follow the unit-specific service and commissioning procedure, then review the CDP fault log before returning the drive to operation.

Order Fulfilment

Payment and Worldwide Delivery

AMIKON coordinates product verification, commercial confirmation, packing and international shipment for industrial automation parts. Each order is handled according to the confirmed model, quantity and delivery destination.
