Question 1: What is the purpose of the ABB NKTT01-3 Termination Cable?

The ABB NKTT01-3 Termination Cable is designed to provide a secure and reliable connection between INFI-Net communication networks and various devices within ABB's industrial control systems. The termination cable is used for signal termination in communication networks, particularly in coaxial-based INFI-Net systems. The NKTT01-3 helps maintain the integrity of the communication link, ensuring reliable communication between connected devices in industrial systems.

Question 2: What are the key features of the ABB NKTT01-3 Termination Cable?

The NKTT01-3 provides proper termination for coaxial cables used in INFI-Net communication networks, which is critical to prevent signal loss or reflection, ensuring smooth data transfer.

Compatibility: Specifically designed to be compatible with ABB’s INFI-Net communication systems, the NKTT01-3 supports various network topologies and ensures that devices connected to the network can communicate effectively.

Question 3: How do I install and troubleshoot the ABB NKTT01-3 Termination Cable?

Power Down the System: Before installing the termination cable, ensure that the power to the INFI-Net network and connected devices is turned off to avoid electrical hazards.

Connect the Cable: Attach one end of the NKTT01-3 cable to the INFI-Net device or network component requiring termination. The other end should be connected to the appropriate coaxial termination point on the network, typically at the last device in the communication chain.

Termination cables like the NKTT01-3 are essential for ensuring that signal outputs from measuring instruments, sensors, or other devices are properly transmitted to control systems or monitoring equipment, making them an integral part of, process control, and monitoring systems.

NKTT01-3 Typically around 0.02 Ω/m, depending on the conductor size and cable length.

Usually greater than 100 MΩ/km, ensuring electrical isolation and preventing leakage.

Common impedance values are 50Ω or 75Ω, catering to different signal transmission requirements, especially for high-frequency or high-speed data communications.

The NKTT01-3 outer diameter of the cable typically ranges from 5 mm to 10 mm, depending on the shielding type and insulation material used.

 The NKTT01-3 is a high-quality termination cable used for ensuring proper signal transmission between devices in control systems. It is designed to handle electrical signals that flow from sensors or other measurement devices to monitoring or control systems in an industrial setup.

This NKTT01-3 termination cable is built to withstand demanding industrial environments. It is designed to endure high vibration, extreme temperatures, and other environmental stresses typical in industrial systems.

The NKTT01-3 cable is compatible with a variety of ABB measurement and control systems, making it a versatile choice for use in different industrial applications.

Temperature Range: -20°C to +80°C (-4°F to +176°F).
