English
Brand/Manufature:
ABBProduct Origin:
SwedenLead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
Coo|
Specification |
Details |
|
Clock Frequency |
24 MHz |
|
Performance, 1000 boolean operations |
0.46 ms |
|
Performance |
0.46 ms |
|
Memory |
12 MB (from 800xA 5.1 FP4) |
|
RAM available for application |
6.253 MB (from 800xA 5.1 FP4) |
|
Processor Type |
MPC860 |
|
No. of Applications per Controller |
32 |
|
No. of Programs per Application |
64 |
|
No. of Diagrams per Application |
128 |
|
No. of Tasks per Controller |
32 |
|
Number of Different Cycle Times |
32 |
|
Cycle Time per Application Programs |
Down to 1 ms |
|
Flash PROM for Firmware Storage |
2 MB |
|
Power Supply |
24 V DC (19.2-30 V DC) |
|
Power Consumption (typ/max) |
+24 V typ: 180 mA / max: 300 mA |
|
Power Dissipation (typ/max) |
4.32 W (7.2 W max) |
|
Built-in Back-up Battery |
Lithium, 3.6 V |
|
Clock Synchronization |
1 ms between AC 800M controllers by CNCP protocol |
|
Supply Current on CEX Bus |
2.4 A |
|
Temperature, Operating |
+5 to +55 °C (+41 to +131 °F) |
|
Temperature, Storage |
-40 to +70 °C (-40 to +158 °F) |
|
Relative Humidity |
5 to 95 %, non-condensing |
|
Emitted Noise |
< 55 dB (A) |
|
Vibration |
10 < f < 50 Hz: 0.0375 mm amplitude, 50 < f < 150 Hz: 0.5 g acceleration, 5 < f < 500 Hz: 0.2 g acceleration |
|
Rated Isolation Voltage |
50 V |
|
Dielectric Test Voltage |
500 V a.c. |
|
Width |
119 mm (4.7 in.) |
|
Height |
186 mm (7.3 in.) |
|
Depth |
135 mm (5.3 in.) |
|
Weight (including base) |
1100 g (2.4 lbs) |
