Brand:ABB

Type: Firing Pulse Transformer Board

Model: SDCS-PIN-H41

Part Number: 3ADT320600R1501

Pulse Voltage: 5–24 V DC

Isolated Pulse Voltage: Typically 10–30 V

Output Current: 1–2 A

Primary-to-Secondary Isolation: ≥2500 V AC

Insulation Resistance: >100 MΩ

Storage Temperature: -40°C to +85°C (-40°F to +185°F)

Operating Temperature: -25°C to +70°C (-13°F to +158°F)

The ABB SDCS-PIN-H41 3ADT320600R1501 Firing Pulse Transformer Board is an integral component used in industrial power control systems. It is designed to convert low-level control signals into high-voltage pulses needed to drive the gate of thyristors or other power semiconductor devices. This board is typically used in applications like motor control, power inverters, and other high-power systems that require precise timing and voltage control for switching.

The SDCS-PIN-H41 3ADT320600R1501 Firing Pulse Transformer Board ensures accurate and reliable transmission of firing pulses, contributing to the smooth operation and efficiency of the power control system. It is engineered for robustness, providing stability under industrial conditions and is often part of the larger ABB and control systems.
