Product Overview

The UVZ-3037 is 3-phase, 37 kW, and has a 200/400-volt class power supply. At 200 volts, it has a 240-350 VDC and 78-amp input and 92-amp, 0-120 Hz, and 0-230 VAC output. At 400 volts, it has an 80 amp and 460-700 VDC input with a 92-amp, 0-460 VAC, and 0-120 Hz output. It has a carrier frequency of 5 kHz. A 37 kW standard inertia VMGF403715 motor is recommended for this unit. It can overload for 1 minute at 150%. It uses SF-HM170BC basic software.  It has a 9600 comm. baud rate.

 The UVZ-3037 is a separate-type inverter unit that has a front cover that protects half of its faceplate. Under the front cover is a power display lamp, the main circuit terminal, and a control circuit terminal. Beside of the front cover are two PG input/output connections, a control signal connection, three communication connectors, a drop number dial, a seven-segment LED monitor indicator, and five small display lamps.

 The UVZ-3037 is UL/C-UL listed. It is in a chassis-style enclosure that should be installed into a control cabinet setup. This unit should only be used in an indoor location that is free of dangerous gas (flammable and corrosive), dust, metal powder, other airborne contaminants, and water/condensation.
