Description：

When combined with a 3300 XL Proximitor Sensor and XLextension cable, the system provides an output voltage thatis directly proportional to the distance between the probe tipand the observed conductive surface. The system canmeasure both static (position) and dynamic (vibration) data.Its primary use is in vibration and position measurementapplications on fluid-film bearing machines, as well asKeyphasor measurement and speed measurementapplications6.

The system provides an accurate, stable signal output over awide temperature range. All 3300 XL Proximity TransducerSystems achieve this level of performance with completeinterchangeability of probe, extension cable, and Proximitorsensor, eliminating the need for individual componentmatchingor bench calibration.

Specification：

Frequently asked questions

Q1: What is the EMERSON PR6424/010-110 used for?

A1: It is used for non-contact vibration and displacement monitoring in rotating machinery systems.

Q2: What are the PR6424/010-110 pulse rise and fall times of the sensor?

A2: The PR6424/010-110 pulse rise and fall times are less than 1 μs.

Q3: What is the PR6424/010-110 dynamic output resistance of the sensor?

A3: The PR6424/010-110 dynamic output resistance is less than 1 kΩ.

Q4: What is the PR6424/010-110 supply voltage range?

A4: The PR6424/010-110 supply voltage range is 10 to 30 VDC.

Q5: What is the PR6424/010-110 permissible ripple level?

A5: The PR6424/010-110 permissible ripple is less than or equal to 10%.

Product Applications

Power and Energy Industry (Steam Turbine Monitoring): Widely used in thermal power plants, nuclear power plants, and gas turbines and hydro turbines. Real-time monitoring of shaft vibration, axial displacement, eccentricity, and speed in large turbine machinery to prevent catastrophic mechanical failures.

Oil, Chemical, and Natural Gas: Monitoring the operating status of high-pressure centrifugal compressors, large fans, and high-speed pumps. Its explosion-proof design (compliant with ATEX/IECEx standards) allows for safe operation in flammable and explosive hazardous areas.

Metallurgy and Heavy Manufacturing: Used in large, high-speed rotating equipment such as steel mill rolling mills and blast furnace blowers to monitor mechanical wear and vibration under long-term continuous operation.

Industrial Water Treatment and Hydraulics: Used in high-power water pumps and large hydroelectric generator units for real-time monitoring of bearing vibration and runout.
