Display Size: 12.1 inches

Display Resolution: 1024 × 768 pixels (XGA)

Display Type: TFT LCD, 16M colors

Brightness: 350 cd/m²

Touch Type: Analog resistive touchscreen

CPU: 32-bit RISC processor

Flash Memory: 128 MB

Operating Voltage: 24 V DC (20–28 V DC range)

Power Consumption: Max. 15 W

Operating Temperature: –10 °C to +50 °C

Storage Temperature: –20 °C to +60 °C

Relative Humidity: Below 85% RH (non-condensing)

Front Panel Protection: IP65F-rated enclosure

Insulation Resistance: 10 MΩ (500 V DC)

Grounding: Class 3 (under 100 Ω)

The Honeywell HCiRD12-10S Controller Interface is a 12.1-inch industrial-grade touchscreen panel engineered for reliable control and monitoring in demanding environments.  Featuring a high-resolution TFT LCD display with 16M colors and an analog resistive touchscreen, it offers clear visualization and precise touch response, even when operated with gloves.  Powered by a 32-bit RISC processor and equipped with 128 MB of flash memory, the HCiRD12-10S provides fast data processing, stable communication with PLCs and DCS systems, and smooth graphical performance.  With its IP65F-rated front panel, wide operating temperature range, and robust resistance to noise and vibration, this controller interface is ideal for factory automation, process control, and machine system integration.
