The MVI56-101M module requires the following minimum hardware and software components:

with compatible power supply and one free slot in the rack, for the MVI56-101M module. The module requires 800 mA of available power.

128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended 00 Mbytes of free hard disk space (or more based on application

requirements)

256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color1024 × 768 recommended)

ProSoft Configuration Builder, HyperTerminal or other terminal emulator program.

Brand: PROSOFT

Model Number: MVI56-101M

Product Type: Communication Module

Protocols Supported: Modbus RTU and Modbus TCP

Modbus RTU (Serial Communication)

Modbus TCP (Ethernet Communication)

Modbus RTU: One or more RS-485 serial ports for Modbus RTU connections.

MVI56-101M  Ethernet port for Modbus TCP/IP communication.

Network Integration: Allows seamless connection of multiple Modbus devices to a single PLC, supporting both Modbus RTU and TCP/IP configurations.

MVI56-101M  Supports both Modbus RTU (serial) and Modbus TCP/IP (Ethernet), providing flexibility for various industrial network setups.

Data Mapping: Maps Modbus data registers directly to the PLC memory, facilitating easy communication with the PLC program.

Modbus RTU/Modbus TCP Ports: The module offers multiple Modbus connections through RS-485 (RTU) or Ethernet (TCP/IP) ports, ensuring compatibility with a wide range of devices.

Real-time Communication: Provides high-speed, real-time data exchange between Modbus devices and  PLCs, which is critical for monitoring applications.

MVI56-101M Built-in configuration tools for setting up Modbus connections, with user-friendly options for device configuration and address mapping.

MVI56-101M Modbus RTU Communication Speed: Supports baud rates up to 115.2 kbps, depending on the network and application requirements.

Modbus TCP Communication Speed: Supports standard Ethernet speeds (10/100 Mbps) for high-speed communication.

I/O Capacity: Supports multiple I/O devices, with configurable data registers and function codes (e.g., holding registers, input registers, coils, discrete inputs).

MVI56-101M  Allows for protocol conversion between Modbus RTU and Modbus TCP, facilitating communication across mixed device networks.

MVI56-101M：-25°C to 70°C (-13°F to 158°F).

Storage Temperature: -40°C to 85°C (-40°F to 185°F).

Humidity: Typically 5% to 95% relative humidity (non-condensing), suitable for industrial environments.
