Empower your industrial control systems with the Prosoft MVI56-MNET Communication Module, designed for seamless integration and high-speed data transfer in challenging environments.

I/O Size:0/120/240 – 16 bit integers

Communication Parameters:Baud Rate: 110 to 115K baud, Stop Bits: 1 or 2, Data size: 7 or 8 Bits, Parity: None, Even, Odd, RTS Timing delays: O to 65535 milliseconds

Floating Point Data Support:Floating point data movement supported, including configurable support for Enron, Daniel® and other implementations

Operating Environment:-40° F to 140° F (0° C to 60° C)

Extended Features:Supports up to 30 clients and 20 servers

Server Capability:Provides access for Human Machine Interfaces (HMIs), Supervisory Control and Data Acquisition (SCADA), or Distributed Control Systems (DCS)

Integrated Software:RSLogix™ 5000 compatible using AOI or ladder file integration

MVI56-MNET No Additional Progrmming Required:No extra PAC/PLC programming needed

MVI56-MNET Ethernet Configuration:10/100 Mbps crossover detection

Application Port:User-definable module data memory mapping up to 5000, 16-bit registers

CIPconnect Support:CIPconnect-enabled network configuration and diagnostics monitoring

Reduced I/O Image Size:Optimized for remote rack implementations

Configuration Builder Software:ProSoft Configuration Builder (PCB) software for streamlined setup

The Prosoft MVI56-MNET Network Interface Module is engineered for seamless integration into industrial control systems, ensuring robust and efficient communication across diverse networks.

MVI56-MNET With its advanced capabilities, this module supports up to 30 client connections and 20 server applications, making it suitable for complex, multi-server environments without compromising network performance.

Innovative features like faster response times and minimized network impact during server failures enhance operational reliability and efficiency.

Equipped with RSLogix™ 5000 compatibility through an Add-On Instruction (AOI) or ladder file, the MVI56-MNET module ensures a smooth integration process without requiring additional programming for Prosoft PLCs.
