Part Number:ATV71HC13N4

Manufacturer: Schneider Electric

Range of Product: Altivar 71

Product or Component Type: Variable Speed Drive

Product Specific Application: Complex, high-power machines

Component Name: ATV71

Motor Power (kW): 132 kW (3-phase, 380…480 V)

Maximum Horse Power Rating: 200 hp (3-phase, 380…480 V)

Maximum Motor Cable Length: 100 m (shielded), 200 m (unshielded)

Power Supply Voltage: 380…480 V (-15…+10 %)

Phase: 3-phase

Line Current: 192 A (480 V, 132 kW / 200 hp), 239 A (380 V, 132 kW / 200 hp)

EMC Filter: Integrated

Assembly Style: With heat sink

Variant: Reinforced version

Apparent Power: 157.3 kVA (380 V, 132 kW / 200 hp)

Prospective Line Isc: 35 kA (3-phase)

Output Frequency: 0.1…500 Hz

Nominal Switching Frequency: 2.5 kHz

Switching Frequency: 2.5…8 kHz adjustable (with derating factor)

Schneider Electric's ATV71HC13N4 is a powerful variable speed drive engineered for comprehensive motor management within industrial systems. This drive accommodates a 3-phase input voltage ranging from 380 to 480 VAC, allowing it to connect to a variety of electrical setups. Its design is compatible with input frequencies spanning 47.5 to 63 Hz, with a maximum input current threshold of 239 A.

On the output side, the ATV71HC13N4 provides a voltage output range of 0 to 480 VAC, delivering effective performance linked to a nominal output current of 259 A. This drive's capability extends to an output frequency starting from a minimum of 0.1 Hz and reaching up to 500 Hz, which makes this drive versatile for varying applications. With an output power rating of 132 kW, equivalent to 200 HP, the drive can manage substantial motor tasks effectively.

In terms of apparent power, the unit is rated at 157.3 kVA, affirming its strength in handling the operational demands. The drive features a standard switching frequency of 2.5 kHz, optimizing performance and efficiency across its functionality. Control is facilitated through an I/O interface, enabling seamless interaction and monitoring during operation. The line SCCR rating of 35 KAIC signifies robust protection against potential short circuits, enhancing operational safety.
