Description：

The 2711P-RDT12H is a PanelView operator terminal component that is specifically used for operator terminals with High Bright display. This PanelView is compatible for use with PanelView Plus and PanelView Plus 6 1250 High-Bright displays. It is designed with a high luminance of 1000 cd/m2 (Nits.). With this High-bright display, compatible PanelView that uses this component may be installed in outdoor locations.

The 2711P-RDT12H comes with an integrated temperature sensor that is used to monitor the temperature of the operator terminal. This temperature sensor enables automatic adjustment of brightness. The 2711P-RDT12H display module may be used DC boards only.

The 2711P-RDT12H comes with a 12.1-inch colored display screen, having a display area of 246 x 184 mm (9.69 x 7.25 in) and pixel resolution of 800 x 600. It also carries the Analog Resistive Touchscreen operator input interface that is rated for 1 million actuations.

Specification：

Frequently asked questions

Q1:Is the 2711P-RDT12H High-Bright Display Module's module replaceable?

A1:Yes, if the replacement logic module has the following replacement part number: 2711P-RP2.

Q2:What is the backlight replacement number for the 2711P-RDT12H Display Module?

A2:The 2711P-RDT12H PanelView Plus Display Module does not have a replacement part.

Q3:What is the rated luminance of the 2711P-RDT12H?

A3:The 2711P-RDT12H has a luminance rating of 1000 cd/m2 (Nits).

Q4:Does the High-bright module come with communication interfaces?

A4:No. The high-bright display module is simply the visualization interface. The communication interfaces are purchased separately.

Q5:Does this module feature an automatic adjustment of brightness?

A5:Yes. The internal temperature sensor triggers the automatic adjustment of brightness when hardware temperature exceeds the rated operating temperature.

Product Applications

Oil and Gas (Extraction and Refining Plants): Commonly used in outdoor drilling platforms, truck-mounted pumping systems, and pipeline pressurization stations in oil fields.

Mining and Heavy Quarrying Plants: Deployed in open-pit mines, crusher control stations, large conveyor belts, and open-pit material storage yards.

Water Treatment and Environmental Protection Plants: Used in urban wastewater treatment plants, open-pit pumping stations, chemical dosing systems, and shore-side control boxes for sedimentation tanks.

Chemical and Dockyard Loading/Unloading Plants: Used in outdoor monitoring scenarios requiring explosion-proof enclosures or placement within stainless steel explosion-proof boxes, such as open-pit storage tank areas in chemical plants, loading and unloading cranes at port logistics terminals, and liquefied gas refueling stations.
