The ABB DSQC266G 3HAB8801-1 is a servo drive axis board designed for use in ABB industrial robotics applications. This board is integral to controlling servo motors, providing precise motion control and feedback capabilities in a variety of systems.

The DSQC266G 3HAB8801-1 is specifically designed for use in ABB's AC500 and AC800 series control systems. It provides a robust platform for interfacing with servo drives, allowing for precise control of motion in applications such as robotics, CNC machines, and other processes. The board features advanced signal processing capabilities, ensuring accurate position and speed control, while also allowing for various configuration options to meet specific application requirements.

Model: DSQC266G

Part Number: 3HAB8801-1

Manufacturer: ABB

Product Type: Servo Drive Axis Board

Power Supply: Typically operates at 24V DC (nominal), with certain configurations allowing for a range of supply voltages.

DSQC266G 3HAB8801-1 Generally operates within a range of 18-30V DC.

DSQC266G 3HAB8801-1  Compatible with various types of encoders (incremental, absolute) for precise position feedback, typically up to 24 bits resolution.

DSQC266G 3HAB8801-1 Typically around 200 mm x 120 mm x 40 mm (length x width x height).

Weight: Approximately 1 kg, ensuring ease of integration within control cabinets.

Operating Temperature Range: Generally operates in the range of -20°C to +60°C (-4°F to +140°F), suitable for various industrial environments.

Humidity Range: Designed to operate in environments with up to 95% non-condensing humidity.

Protection Class: Typically rated IP20, suitable for indoor use.
