The ABB DSQC266T 3HAB8802-1 is a servo drive board designed for precise motion control in industrial robotics applications. This board is part of ABB's extensive range of control solutions, enabling seamless integration with various servo drives and enhancing the performance of systems.

The DSQC266T 3HAB8802-1 servo board provides advanced capabilities for controlling servo motors in applications requiring high precision, speed, and torque management. It is compatible with ABB's control systems and is typically used in conjunction with other components in robotics, CNC machinery, and similar applications. The board allows for sophisticated motion control strategies, ensuring responsive and accurate movements tailored to specific operational needs.

Model: DSQC266T

Part Number: 3HAB8802-1

Manufacturer: ABB

Product Type: Servo Drive Board

Power Supply Voltage: Usually operates at a nominal voltage of 24V DC, but may support a range from 18V to 30V DC.

Input Voltage Range: Typically operates within 18-30V DC.

DSQC266T 3HAB8802-1 Capable of high-speed data transfer, usually around 1 Mbps, facilitating real-time communication for motion control.

DSQC266T 3HAB8802-1  Compatible with a variety of encoders (incremental and absolute) for accurate position feedback, typically up to 24 bits resolution.

DSQC266T 3HAB8802-1 Dimensions: 200 mm x 120 mm x 40 mm (length x width x height).

Weight: Generally around 1 kg, facilitating easy integration within control panels or cabinets.

Operating Temperature Range: Generally operates in the range of -20°C to +60°C (-4°F to +140°F), suitable for various industrial environments.

Humidity Range: Designed to function in environments with up to 95% non-condensing humidity.

Equipped with LED indicators for power status, communication, and operational status, enabling easy monitoring and diagnostics.
