Brand/Manufature:
EPROProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
CooBrand:EPRO
Model:PR9268/017-100
Type:Electrodynamic Velocity Sensor
Sensitivity: 17.5 mV/mm/s
Frequency Range: 14 to 1000 Hz
Natural Frequency: 14 Hz ± 7% @ 20°C (68°F)
Transverse Sensitivity: < 0.1 @ 80 Hz
Vibration Amplitude: 500 µm peak-peak
Amplitude Linearity: < 2%
Maximum Transverse Acceleration: 2g (19.62 m/s²)
Damping Factor: ~0.6% @ 20°C (68°F)
Resistance: 1723 Ω ± 2%
Inductance: ≤ 90 mH
Active Capacity: < 1.2 nF
The EPRO PR9268 is a mechanical velocity sensor designed for absolute vibration measurement in critical turbomachinery applications, such as steam, gas, and hydro turbines, compressors, pumps, and fans to measure case vibration. It is available in a variety of orientations and cable lengths, and can be supplied with or without a Harting connector.
Key specifications include:
Sensitivity: 17.5 mV/mm/s (01x-x00) or 28.5 mV/mm/s (20x-x00, 30x-x00)
Frequency Range: 14 to 1000 Hz
Natural Frequency: 4.5 Hz ± 0.75 Hz @ 20°C (68°F)
Maximum Acceleration: 10g (98.1 m/s²) continuous, 20g (196.2 m/s²) intermittent
Maximum Transverse Acceleration: 2g (19.62 m/s²)
