Brand: GE Fanuc

Series: Field Control

Part Number: IC670ALG630

Number of Channels: 8

Thermocouple Types: J, K, T, E, S, R, B, N, G, C, D, Platinel II

Spans (±): 19.5 mV, 39 mV, 78.125 mV, 156.25 mV, 312.5 mV, 625 mV

Converter Resolution: 15 bits + sign

Temperature Sensitivity (0 to 60°C): ±0.004% of reading, ±1.5 mV/°C referred to input

Maximum Voltage Between Channels: 250 VAC

Current Drawn from BIU Power Supply: 195 mA maximum

Fault Detection: Open thermocouple, over/under range, and high/low alarm

The GE Fanuc IC670ALG630 Thermocouple Input Module allows for the connection of 8 temperature signals for the intelligent processing of those signals by a Genius PLC. Because up to 8 of these modules can be connected to a single BIU, this gives it the capability to process 64 independent thermocouple signals automatically according to the final user’s control algorithm.

The GE Fanuc IC670ALG630 Field Control Module is specialized to receive voltage signals in the order of millivolts coming from thermocouple sensors. The IC670ALG630 Analog Input Module for thermocouples can receive up to 8 independent input signals using 8 customizable channels to handle temperature changes in the order of one tenth of a degree (Fahrenheit or Celsius). Up to 8 GE Fanuc IC670ALG630 Thermocouple Input Modules can be linked to a GE Fanuc BIU (Bus Interface Unit), making it able to receive and process up to 64 independent temperature measurements in a single, small, and powerful control system. The configuration of the reference parameters of each Field Control module is stored in the BIU and the configuration can be customized by using a proprietary handheld programmer.
