Model: IC695HSC304-DA

Platform: PACSystems RX3i

Counter Channels: 4 independent counters

Input Channels: 8 high-speed inputs

Output Channels: 7 high-speed outputs

Max Count Frequency: Up to 1.5 MHz depending on counter type

Response Time: ≤2 us

Backplane Current: 80 mA@ 5VDC,125 mA@24VDC

Input Voltage: 24 VDC (±10%)

Mounting Format: RX3i Universal Backplane

Hot Swap Capability: Supported

Operating Temperature: 0°C to +60°C

The IC695HSC304-DA module is a high-speed counter module. The IC695HSC304-DA module can be installed in RX3i PacSystems series industrial control systems. Applications that are ideal for high-speed counters include motion control, process control, material handling, and velocity measurement applications. The IC695HSC304-DA module can be used for processing rapid pulse signals of up to 1.5 Megahertz. The IC695HSC304-DA module provides 8 high-speed inputs, 7 high-speed outputs, and 1 to 4 counters. Features of the IC695HSC304-DA module include terminal bock insertion and removal detection, programmable I/O interrupts, upgradable flash memory, and module fault reporting. The module can operate with 2 voltage input ranges of 4.7 to 5.5 Volts DC and 10 to 26.4 Volts DC. The peak input voltage rating is 35 Volts DC. The output current rating is a maximum of 1.5 Amps per channel and a maximum of 10.5 Amps per module.
