Part No.: IS200ECTBG1ADE

Manufacturer: General Electric

Country of Manufacture: United States of America (USA)

Temperature Operating: -30 to 65 o C

Product Type: Exciter Contact Terminal Board

Supported Wire Gauge: 14–22 AWG

Voltage Rating: 24–125 VDC typical for signal applications

Insulation Resistance: >100 MΩ at 500 VDC

IS200ECTBG1ADE is an Exciter Contact Terinal Board developed by GE I is a part of EXZ100 exciation system. The terinal board faciitates excitation contactoutputs and inputs wihin the EX2 100 Excitation Contro system. There are two distinctversions of this terminal board: the ECTBG1 board,utized exclusively in redundantontro scenarios, and the ECTBG2 board,employed solely in simplex contal configurations. Each board s equiped with specific functionalities talored to its respectivecontrol setup.

Frequently asked questions：

1.What is IS200ECTBG1ADE?

It is an exciter contact terminal board developed by GE under the EX2100 series.

2.What is the GE IS200ECTBG1ADE used for?

The GE IS200ECTBG1ADE Exciter Contact Terminal Board is used in excitation control systems to provide terminal connections for signal wiring between control modules and field devices.

3.What wire gauge is supported by the GE IS200ECTBG1ADE?

A: The GE IS200ECTBG1ADE supports 14–22 AWG wiring, allowing flexible installation for various signal connections.

4.What is the typical voltage rating of this terminal board?

The GE IS200ECTBG1ADE is typically rated for 24–125 VDC signal applications.

5.What is the insulation resistance of the GE IS200ECTBG1ADE?

The terminal board provides insulation resistance greater than 100 MΩ at 500 VDC, ensuring reliable electrical isolation.

System Role and Compatibility

Series: Primarily part of the Mark VI Speedtronic and EX2100 Excitation Control systems used for gas, steam, and wind turbine management.

Redundancy: This "G1" variant is for redundant systems; the "G2" variant is typically used for simplex modes.

Revisions: The "ADE" suffix indicates this specific unit has undergone two functional revisions (A and D) and an artwork configuration revision (E).
