The GE IS200STTCH2A Mark VI printed circuit board is a core component in industrial systems, designed for seamless integration and enhanced operational efficiency in various manufacturing environments.

Dimensions:175mm x 100mm x 35mm

Weight:0.5kg

Operating Temperature Range:-20°C to +70°C

Communication Protocol:MODBUS RTU, CANopen

Input Voltage:12V DC

Output Current:1A per channel

Number of Channels:8 Input / 8 Output

Protocol Compatibility:IEC 61131-3

The GE IS200STTCH2A is engineered for high reliability and performance in demanding industrial settings, featuring advanced diagnostics and self-monitoring capabilities.

With its robust design and wide temperature range compatibility, this IS200STTCH2A module ensures stable operation under extreme conditions, making it ideal for harsh industrial environments.

Equipped with state-of-the-art communication interfaces, the IS200STTCH2A facilitates seamless integration with existing control systems, enhancing system flexibility and interoperability.

Offering a versatile combination of 8 input and 8 output channels, this IS200STTCH2A module provides extensive connectivity options for various sensors and actuators, enabling precise control over machinery and processes.

The GE IS200STTCH2A is a  Mark VI printed circuit board designed for use with the Mark VI Speedtronic system. This terminal board is crucial for integrating thermocouples with turbine control systems, commonly found in heavy-duty steam and gas turbines managed by GE's Speedtronic controls.

IS200STTCH2A On one side, the board features a 48-position terminal strip, divided into two lines for easy wire connection. This allows for quick and efficient connections to the board, simplifying maintenance and expansion.

IS200STTCH2A  On the other side of the board, a 37-position female DC connector is placed at the center for connecting to the control system, facilitating smooth data communication between components.
