Manufacturer: General Electric (GE)

Model Number: IS200TBTCH1BBB

Product Type: Turbine Control Card

Power Supply: 24 VDC

Operating Temperature: approximately −40°C to +70°C

Humidity: 5–95% non-condensing

General Electric or GE developed the IS200TBTCH1BBB thermocouple terminal board as one of the components in the Mark VI series. The Mark VI and the several other series in the Mark lineup were developed for the control and of industrial turbines which run on gas and/or steam. The IS200TBTCH1BBB is a type of PCB, short for printed circuit board. The Mark VI Turbine Control System Series that this IS200TBTCH1BBB Thermocouple Terminal Board was manufactured for, as it is known at length, exists with a specific set of possible functional applications in the control and management systems of General Electric-compatible gas, steam, and even wind turbine control system automated drive assembly. This must be considered quite the massive functional step up from the previous industry-standard Mark V Turbine Control System Series of the same full extended series name, as it added the wind turbine possible application to the gas and steam applications seen in the Mark V. This IS200TBTCH1BBB device's Mark VI Series is also highly-desired as a function of its status as one of the last-developed GE Mark product series utilizing the patented Speedtronic control system technology.

Frequently asked questions：

1. What is the function of the GE IS200TBTCH1BBB card?

It acts as a turbine control interface board, processing signals between field sensors, actuators, and the Mark VI control system.

2. Which control systems use this module?

The IS200TBTCH1BBB is designed for GE Speedtronic Mark VI turbine control systems used in gas and steam turbine applications.

3. What types of signals does the IS200TBTCH1BBB board handle?

The board typically supports analog and digital signals related to turbine parameters such as temperature, pressure, speed, and status signals.

Functional Overview

The board serves as the interface between external thermocouple sensors and the turbine's digital control system.

Thermocouple Support: It is designed to accept various thermocouple types (typically E, J, K, S, or T) and transmit this data for real-time monitoring and response.

Diagnostics: The board includes hardware and software high/low limit checks and monitor diagnosis for each thermocouple and cold junction (CJ).

Component Layout: The board is populated with two long lines of blue resistors and multiple rows of silver capacitors to ensure signal integrity and surge protection.
