General Electric IS220PAOCH1BE Analog Output Module

Dimensions:

13cmx7.2cmx6.5cm

Weight:

0.28kg

Input Current:

  105mA

Voltage :

12V

The IS220PAOCH1BE is a GE Analog I/O pack from the Mark VIe series. The PAIC pack serves as the electrical interface between one or two I/O Ethernet networks and an analog input terminal board. The pack includes a processor board shared by all Mark VIe distributed I/O packs and an acquisition board dedicated to the analog input function.

The pack can handle up to ten analog inputs, the first eight of which can be configured as 5 V or 10 V inputs or 0-20 mA current loop inputs. The last two inputs can be set to 1 mA or 0-20 mA current inputs

IS220PAOCH1BE

IS220PAOCH1BE is a Analog Output Module manufactured and designed by General Electric as part of the Mark VIe Series used in distributed control systems.The Power Distribution System Feedback (PPDA) I/O pack can receive inputs from as many as six power distribution boards or as many as six sets of feedback signals.

The Mark VIe Control Power Distribution Module's JPDS, JPDM, JPDG, or JPDC 28 V de control power distribution board serves as the host for the PPDA I/O pack (PDM). 50-pin ribbon cable jumpers wired pin to pin 1 are used to connect other boards. The PPDA receives one feedback group from each board.
