Bently Nevada 3300 XL Proximitor Sensor Accessories

138492-01

Price and Availability Inquiry

The Bently Nevada 138492-01 is the replacement panel-mount mounting pad listed for 3300 XL Proximitor Sensor installations; it is a mounting accessory, not a probe or active sensor.

Sales SupportDirect specialist contact

QuotationCurrent commercial details

DeliveryDHL · FedEx · UPS

Fast quotation support Send the model and required quantity directly to Lisa Lin using the contact options on the right.

Your AMIKON Contact

LL Lisa LinSales Specialist

WhatsApp +86 18965423501

Email sales7@amikon.cn

Request a Quote on WhatsApp Send Email Inquiry

For faster service, please include the model 138492-01 and required quantity in your inquiry.

Bently Nevada 138492-01

Technical Specifications

138492-01 pad data and clearly labeled 3300 XL 8 mm Proximitor reference specifications.

01Product IdentityManufacturer accessory listing

ManufacturerBently Nevada

Article number138492-01

DesignationReplacement panel-mount mounting pad

Product family3300 XL Proximitor accessories

02Mounting InterfaceVerified accessory application

Mounting orientationPanel mount

Accessory roleReplacement mounting pad

Associated component3300 XL Proximitor Sensor

DIN-mount alternate138493-01 (separate part)

03Panel-Mount Installation3300 XL 8 mm Proximitor reference

Panel mounting pattern4-hole

Panel screw sizeM3.5 or #6

Screws per sensor4

Panel screw part04310310

04Related 8 mm Sensor Data3300 XL 8 mm system, not pad ratings

Sensor supply, no barrier−17.5 to −26 V DC

Sensor current, max.12 mA

Sensor output resistance50 Ω

System frequency response0–10 kHz (+0 / −3 dB)

Bently Nevada 138492-01 Product Support

Frequently Asked Questions

Product-specific configuration, compatibility, application and ordering guidance for 138492-01.

Which mounting format does 138492-01 support?

The manufacturer lists 138492-01 as the replacement panel-mount mounting pad for a compatible Proximitor Sensor arrangement.

How is the DIN-mount spare distinguished?

The separately listed DIN-mount replacement pad is 138493-01; do not order it in place of the panel-mount part.

Does this pad provide a sensing signal or supply connection?

No. It is a passive mounting accessory, not a proximity probe or Proximitor Sensor; sensing range and supply ratings do not apply to the pad itself.

Which panel-mount fasteners are listed separately?

The manufacturer lists 04310310 as a panel-mount screw, with four screws required per Proximitor Sensor. Confirm whether fasteners are needed in the order.

How should the mounting footprint be checked?

Compare the installed Proximitor housing and four-hole panel layout with the replacement pad before removing the existing mount.

How should isolation be considered during installation?

The manufacturer states that the 3300 XL sensor mounting base provides electrical isolation. Check the complete mounting and grounding arrangement rather than treating the pad alone as an electrical specification.

Which details should accompany a replacement-pad order?

Provide 138492-01, the installed Proximitor Sensor part number, panel-mount drawing or photos, quantity and any required mounting screws.
