Brand/Manufature:
Bently NevadaProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
CooClaim Your Exclusive Savings – Get in Touch with Sales Manager Lisa Lin Now
: +86-18965423501
: sales7@amikon.cn
:AMKPLC
|
Brand |
Bently Nevada |
|
Model |
190501-24-00-CN |
|
Product Type |
Velomitor CT Velocity Transducer |
|
Mounting Hardware 24 |
Adapter, 3/8-in 24 to 1.25-in 11.5 NPT |
|
Connection 00 |
MIL-C-5015 connection interface |
|
Agency Approval CN |
China Ex / NEPSI certification |
|
Transverse Response |
Less than 5% of the axial sensitivity |
|
Amplitude Linearity |
±2% up to 63.5 mm/s pk (2.5 in/s pk) |
|
Typical Dynamic Output Impedance |
<400 Ω |
|
Standard Sensitivity |
3.94 mV/mm/s (100 mV/in/s) ±5% |
The Velomitor CT Velocity Transducer is a low-frequency version of our standard Velomitor Piezo-velocity Sensor. Its design specifically measures casing vibration velocity on cooling tower and air-cooled heat-exchanger fan assemblies that operate at or above 90 rpm (100 to 300 rpm typical).
The Velomitor CT Transducer can measure vibration amplitudes at these frequencies as well as the vibration frequencies generated by the fan motor and speed reducer.
In addition, be careful to install the accelerometer transducer on the bearing housing or machine casing. Improper installation may decrease the transducer amplitude and frequency response and/or generate false signals that do not represent actual vibration. Refer to the appropriate instruction manuals and Application Notes.
Upon request, Bently Nevada provides engineering services that can identify the appropriate machine housing measurements and installation assistance if needed.
Frequently Asked Questions
1. What is the Bently Nevada 190501-24-00-CN Velomitor CT Velocity Transducer?
The Bently Nevada 190501-24-00-CN is a Velomitor CT Velocity Transducer designed to measure casing vibration on low-speed rotating machinery, including cooling tower fans, air-cooled heat exchangers, pumps, and electric motors.
2. What does Mounting Hardware Code 24 mean?
Mounting Hardware Code 24 specifies an adapter with a 3/8-inch 24 thread to a 1.25-inch 11.5 NPT connection. This adapter enables installation on equipment using a 1.25-inch 11.5 NPT threaded mounting interface.
3. What is the amplitude linearity of the 190501-24-00-CN transducer?
The 190501-24-00-CN provides an amplitude linearity of ±2% up to 63.5 mm/s peak (2.5 in/s peak), ensuring accurate and repeatable vibration measurements throughout its specified operating range.
4. What is the 190501-24-00-CN typical dynamic output impedance?
The 190501-24-00-CN transducer has a typical dynamic output impedance of less than 400 Ω, allowing stable signal transmission over long cable distances while maintaining measurement accuracy.
Product Applications
Petrochemical and oil refineries: Monitor the vibration of large cooling tower fans and air coolers to prevent damage to blades or bearings.
Thermal power plants: Monitor the casing vibration of large fan equipment such as induced draft fans, forced draft fans, and primary air fans.
Water and wastewater treatment plants: Monitor the operating status of large low-speed water pumps and aeration fans.
Metallurgical and cement plants: Used for mechanical protection of large exhaust systems and heavy-duty low-speed rotating equipment.
