The 20015x Accelerometers are general-purpose, wide-frequency, case-mounted seismic transducers designed for use with Trendmaster proTIMs. The 200150 Accelerometer also operates with the Trendmaster2000 system. It interfaces with the 200100 Dual Acceleration to Velocity flexiTIM Module and the 89130-01 Acceleration-to-Velocity TIM (Transducer Interface Module), as well as the 1900/25 and 1900/27 monitors.

The 20015x Accelerometers feature a hermetically sealed, stainless steel case. This design provides an extremely rugged transducer that is well-suited for harsh industrial environments. The transducer’s top-mounted, 5-pin connector allows you to easily install and remove the interconnecting signal cable. A 3/8-24 threaded hole on the bottom of the sensor’s casing accommodates several mounting options.

The 20015x Accelerometers contain a piezoelectric sensing device that generates a charge when subjected to vibration. The accelerometers electronically convert this charge to a differential voltage signal that is proportional to the acceleration parallel to the sensitive axis of the transducer.

Frequently Asked Questions

Q1: What is the Bently Nevada 200155-18-CN Trendmaster Pro Accelerometer?

A1: It is an industrial accelerometer designed for vibration monitoring and machinery condition monitoring within Trendmaster Pro systems.

Q2: What does the 200155-18-CN mounting stud option “18” indicate?

A2: The “18” option specifies a 3/8-24 to M8×1 mounting stud with a 1-3/8 inch hex plate stud configuration.

Q3: What is the 200155-18-CN output bias voltage of this accelerometer?

A3: The 200155-18-CN output bias voltage is +2.5 V DC with a tolerance of ±0.23 V DC.

Q4: What is the 200155-18-CN recommended mounting torque?

A4: The recommended mounting torque is 2.7 to 6.8 N•m (2 to 5 ft•lbf).

Q5: What is the 200155-18-CN main function of this accelerometer?

A5: Its main function is to measure vibration levels in rotating machinery for predictive maintenance, fault detection, and condition monitoring.

Product Applications

Power Generation and Electricity Industry: Monitoring vibrations in fans, large fans, large bearings, and rotating machinery to ensure continuous power generation.

Oil and Gas (Petrochemical): Online monitoring of oil pipeline pumps, compressors, and fin-fans.

Paper and Pulp Industry: Monitoring slow-moving rollers and dryers.

Mining and Cement: Health maintenance of heavy, low-speed equipment such as conveyor belt rollers and large crushers.
