Manufacturer |
Bently Nevada |
|
Product No. |
200157-18-CN |
|
Product Type |
Enveloping Trendmaster Pro Accelerometer |
|
Origin |
Made in U.S.A |
|
Certificate of Origin (COO) |
Available upon request |
|
Mounting Stud Option (18) |
3/8‑24 to M8×1 1‑3/8 inch hex plate stud |
|
Agency Approval (CN) |
Country‑specific China approvals (reference guide & notification letter downloadable) |
|
Sensitivity @ 80 Hz (±12%) |
10.2 mV/(m/s²) (100 mV/g) |
|
Measurement Range |
±245 m/s² (±25 g) |
|
Axial Shock Limit |
49,050 m/s² pk (5,000 g pk) |
|
Temperature Range |
-40 °C to +105 °C (-40 °F to +221 °F) |
|
Hermetic Sealing |
Max. 5×10⁻⁸ atm·cc/s (3.1×10⁻⁹ atm·in³/s) |
|
Relative Humidity |
100% RH, condensing, non‑submerged |
|
Electrical Connector (Top) |
5‑pin 1/2‑20 |
|
Housing & Connector Material |
316L stainless steel |
|
Mounting Torque |
2.7–6.8 N·m (2–5 ft·lbf) |
|
Mounting Thread |
3/8‑24 female |
|
Dimension (Hex × Height) |
1.75 cm × 4.57 cm (11/16 in × 1.8 in) |
|
Net Weight |
0.058 kg |
|
Shipping Weight |
1 kg |
The 200157Accelerometers are general-purpose, wide-frequency, case-mounted seismic transducers designed for use with Trendmaster ProTIMs. The 200150 Accelerometer also operates with the Trendmaster 2000 system. The accelerometer interfaces with the 200100 Dual Acceleration to Velocity flexiTIM Module and the 89130-01 Acceleration-to-Velocity TIM (Transducer Interface Module), as well as the 1900/25 and 1900/27 monitors.
The 200157 Accelerometers feature a hermetically sealed, stainless steel case. This design provides an extremely rugged transducer that is well-suited for harsh industrial environments. The transducer’s top-mounted, 5-pin connector allows easy installation and removal of the interconnecting signal cable. A 3/8-24 threaded hole on the bottom of the sensor’s casing accommodates several mounting options.
Frequently Asked Questions
Q1: What is the Bently Nevada 200157-18-CN Enveloping Trendmaster Pro Accelerometer?
A1: It is an industrial accelerometer used for vibration monitoring, enveloping analysis, and machinery condition assessment in predictive maintenance systems.
Q2: What mounting stud configuration is used in the 200157-18-CN model?
A2: The 200157-18-CN mounting stud option “18” uses a 3/8-24 to M8 × 1, 1-3/8 inch hex plate stud configuration.
Q3: What is the 200157-18-CN measurement range of this accelerometer?
A3: The 200157-18-CN measurement range is ±245 m/s² (±25 g).
Q4: What is the 200157-18-CN axial shock limit?
A4: The axial shock limit is 49,050 m/s² peak (5,000 g peak).
Q5: What is the 200157-18-CN operating temperature range?
A5: The 200157-18-CN operating temperature range is -40°C to +105°C (-40°F to +221°F).
Product Applications
Power Industry: Vibration monitoring of large rotating machinery such as generators, steam turbines, and fans.
Oil and Gas: Health status monitoring of critical equipment such as drilling platforms, compressors, and pump sets.
Chemical and Petrochemical Industry: Petrochemical reactors, circulating pumps, high-speed centrifuges, etc.
Metallurgy and Steel Industry: Blast furnace blowers, hot/cold rolling mills, and large conveyor systems.
Cement and Glass Industry: Large equipment such as vertical mills and rotary kilns.
Pharmaceutical Industry: High-precision rotating equipment.
