Brand/Manufature:
Bently NevadaProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
CooClaim Your Exclusive Savings – Get in Touch with Sales Manager Lisa Lin Now
: +86-18965423501
: sales7@amikon.cn
:AMKPLC
|
Manufacturer |
Bently Nevada |
|
Model Number |
330101-00-07-10-02-05 |
|
Type |
Proximity Probes |
|
Capacitance |
69.9 pF/m |
|
Minimum Target Size |
15.2 mm (0.6 in) diameter (flat target) |
|
Minimum Target Distance |
Minimum 50.8 mm (2 in) |
|
Recommended Target Distance |
Minimum 76.2 mm (3 in) |
|
Probe Tip Material |
Polyphenylene sulfide (PPS) |
|
Minimum Cable Bend Radius |
25.4 mm (1.0 in) |
|
Maximum Connector Torque |
0.565 N•m (5 in•lbf) |
|
Proximitor Sensor Material |
A308 aluminum |
|
Total System Weight (Typical) |
0.7 kg (1.5 lbm) |
|
Probe Weight |
323 g/m (11.4 oz) |
|
Extension Cable Weight |
34 g/m (0.4 oz/ft) |
|
Armored Extension Cable Weight |
103 g/m (1.5 oz/ft) |
|
Proximitor Sensor Weight |
246 g (8.67 oz) |
The 3300 XL probe and extension cable alsoreflect improvements over previous designs. Apatented Tiploc molding method provides amore robust bond between the probe tip andthe probe body. The probe's cable incorporatesNs bpu stengtniore securely otachthe probe cable and probe tip.
You can also order 3300 XL 8 mm probes and extension cables with an optional FluidLoccable option. This option prevents oil and otherliquids from leaking out of the machine throughthe cable's interior.
Frequently Asked Questions
What is the diameter of the probe tip for this 330101-00-07-10-02-05 model?
The probe tip diameter is 8 mm, which determines its standard linear range.
What is the standard linear range of a 3300 XL 8mm probe?
The standard linear range is 2.0 mm (80 mils), starting at approximately 0.25 mm (10 mils) from the probe face.
What is the standard Scale Factor (ASF) for this system?
The standard incremental scale factor is 7.87 V/mm (200 mV/mil) when paired with the correct 3300 XL Proximitor.
What does the "-10" option mean?
It specifies a 1.0-meter (approx. 3.3 feet) integrated probe cable length.
Product Applications
Oil & Gas Plants: Liquefied Natural Gas (LNG) plants, oil refineries, crude oil pumping stations.
Power Generation: Conventional coal-fired power plants, conventional islands of nuclear power plants, large hydroelectric power plants.
Petrochemical & Ethylene Plants: Ethylene cracking units, synthetic ammonia plants, air separation units (oxygen/nitrogen production plants).
Steel & Metallurgical Mills: Blast furnace blower rooms, large rolling mills, blast furnace gas recovery power generation (TRT) units.
General Industrial Plants: Large cement plants, pharmaceutical air compressor stations, large paper mills.
|
1)100% full New! - Original Factory Seal ! |
|
2)We have DHL,UPS,TNT ，customers can also use their own freight forwarders. |
|
3)Package: Original packing with cartons. |
|
4)Delivery time: Shipped in 3 days after payment. |
|
5)Strict packaging to ensure safe arrival at destination. |
1. Are your product brand-new and original?
Yes,100% brand-new and original products.
2.How long is the quality guarantee for your products?
All our products with 1 year warranty.
3.When will you delivery the goods?
With stock, we will arrange delivery in about 3 to 5 days; without stock, it will take relatively long time, but it won't be too long, it mainly depends on order quantity.
4.What are your terms of payment?
100% advance payment through T/T bank wire transfer
Amikon sells new and surplus products and develops channels to purchase such products.
This site is not approved or endorsed by any of the listed manufacturers or trademarks.
Amikon is not an authorized distributor, dealer or representative of the products displayed on this site.
All product names, trademarks, brands and logos used on this site are the property of their respective owners.
The description, illustration or sale of products under these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
